Festo Pneumatic Cylinder - 1908261, 16mm Bore, 30mm Stroke, DSNU Series, Double Acting
- RS Stock No.:
- 136-6614
- Mfr. Part No.:
- DSNU-16-30-P-A
- Brand:
- Festo
Subtotal (1 unit)*
£50.20
(exc. VAT)
£60.24
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 15 unit(s) ready to ship
- Plus 7 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £50.20 |
*price indicative
- RS Stock No.:
- 136-6614
- Mfr. Part No.:
- DSNU-16-30-P-A
- Brand:
- Festo
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Festo | |
Manufacturer Series | DSNU | |
Model Number p | 1908261 | |
Bore | 16mm | |
Stroke | 30mm | |
Action | Double | |
Port Connection | M5 | |
Pneumatic Connection | M5 | |
Piston Rod Thread Gender | Male | |
Cushioning Type | Elastomer | |
Dimensions | 20 x 141mm | |
Length | 141mm | |
Diameter | 20mm | |
Maximum Operating Pressure | 10 bar | |
ISO Standard | ISO 6432 | |
Weight | 103.7g | |
VDMA Standard | VDMA24364-B1/B2-L | |
Stroke Interval Weight | 2 g @ 10 mm Stroke | |
Minimum Operating Temperature | -20°C | |
Test Weight | 23 g @ 0 mm Stroke | |
Maximum Operating Temperature | +80°C | |
Select all | ||
---|---|---|
Brand Festo | ||
Manufacturer Series DSNU | ||
Model Number p 1908261 | ||
Bore 16mm | ||
Stroke 30mm | ||
Action Double | ||
Port Connection M5 | ||
Pneumatic Connection M5 | ||
Piston Rod Thread Gender Male | ||
Cushioning Type Elastomer | ||
Dimensions 20 x 141mm | ||
Length 141mm | ||
Diameter 20mm | ||
Maximum Operating Pressure 10 bar | ||
ISO Standard ISO 6432 | ||
Weight 103.7g | ||
VDMA Standard VDMA24364-B1/B2-L | ||
Stroke Interval Weight 2 g @ 10 mm Stroke | ||
Minimum Operating Temperature -20°C | ||
Test Weight 23 g @ 0 mm Stroke | ||
Maximum Operating Temperature +80°C | ||
- COO (Country of Origin):
- DE
Festo Pneumatic Cylinder, 1 Bar Minimum Operation Pressure, 120.6N Theoretical Return Force - DSNU-16-30-P-A
Pushing and pulling equipment is a walk in the park with this double-acting pneumatic cylinder from Festo. Its 16mm bore and 30mm stroke comfortably control up to 10 bar of pressure to position, clamp and eject components with ease. The elastomer buffers on either end absorb up to 0.15J of impact energy to prevent the piston from suffering or causing damage. You can install the unit with a foot mounting (121-4365) or clevis foot (121-5632) in any position needed to suit your setup.
Features & Benefits
• Wide operating temperature range between -20°C and +80°C to suit demanding environments
• Standard M5 pneumatic connection for quick installation in your current setup
• NBR seals stop debris getting in, to prolong service life
• Streamlined dimensions of 20 (D) x 141 (L) for space-saving installation in small systems
• Standard M5 pneumatic connection for quick installation in your current setup
• NBR seals stop debris getting in, to prolong service life
• Streamlined dimensions of 20 (D) x 141 (L) for space-saving installation in small systems
Applications
• Manufacturing systems
• Construction equipment
• Warehouse facilities
• Construction equipment
• Warehouse facilities
Can I add a proximity sensor to this device?
Yes, you can improve control over the piston's location by adding an SMT (121-5836) or SDBT-series proximity sensor (253-9245). To attach it, simply use the SMBR-series mounting kit (121-5566).
