EMERSON – ASCO G653 series 25 μm 3/4 in 12 bar Pneumatic Filter 4700 L/min max with Semi Automatic drain
- RS Stock No.:
- 328-647
- Mfr. Part No.:
- G653ABJP5JA000N
- Brand:
- EMERSON ? ASCO
Subtotal (1 unit)*
£120.04
(exc. VAT)
£144.05
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 18 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £120.04 |
*price indicative
- RS Stock No.:
- 328-647
- Mfr. Part No.:
- G653ABJP5JA000N
- Brand:
- EMERSON ? ASCO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | EMERSON ? ASCO | |
| Product Type | Pneumatic Filter | |
| Filtration Size | 25μm | |
| Port Size | 3/4 in | |
| Connection Thread Standard | ISO 7/1 Rc, Rc | |
| Drain Type | Semi Automatic | |
| Series | G653 | |
| Maximum Flow Rate | 4700L/min | |
| Seal Material | Nitrile Rubber (NBR) | |
| Maximum Operating Pressure | 12 bar | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | 50°C | |
| Standards/Approvals | ISO 12500, RoHS Status: Exempt, CUTR, ATEX, ISO 8573.1:2010 | |
| Bowl Material | Polycarbonate | |
| Filter Type | Air Filter | |
| Select all | ||
|---|---|---|
Brand EMERSON ? ASCO | ||
Product Type Pneumatic Filter | ||
Filtration Size 25μm | ||
Port Size 3/4 in | ||
Connection Thread Standard ISO 7/1 Rc, Rc | ||
Drain Type Semi Automatic | ||
Series G653 | ||
Maximum Flow Rate 4700L/min | ||
Seal Material Nitrile Rubber (NBR) | ||
Maximum Operating Pressure 12 bar | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature 50°C | ||
Standards/Approvals ISO 12500, RoHS Status: Exempt, CUTR, ATEX, ISO 8573.1:2010 | ||
Bowl Material Polycarbonate | ||
Filter Type Air Filter | ||
RoHS Status: Exempt
The Asco Particulate Filter offers a large selection of filtering capacities to effectively remove particulate matter and water droplets from compressed air or inert gas systems. It features sintered polyethylene elements combined with a centrifugal separator, providing superior filtration.
Threaded ports allow for individual or modular mounting
Air purity class according to ISO 8573 1 2010
