EMERSON – ASCO G653 series 25 μm G 1 12 bar FRL Assembly 5000 L/min max with Semi Automatic drain
- RS Stock No.:
- 328-649
- Mfr. Part No.:
- G653ABJP6JA000A
- Brand:
- EMERSON ? ASCO
Subtotal (1 unit)*
£166.68
(exc. VAT)
£200.02
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 + | £166.68 |
*price indicative
- RS Stock No.:
- 328-649
- Mfr. Part No.:
- G653ABJP6JA000A
- Brand:
- EMERSON ? ASCO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | EMERSON ? ASCO | |
| Filtration Size | 25μm | |
| Product Type | FRL Assembly | |
| Port Size | G 1 | |
| Connection Thread Standard | G | |
| Drain Type | Semi Automatic | |
| Series | G653 | |
| Seal Material | Nitrile Rubber (NBR) | |
| Maximum Flow Rate | 5000L/min | |
| Maximum Operating Pressure | 12 bar | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | 50°C | |
| Standards/Approvals | ISO 12500, ATEX, CUTR, RoHS Status: Exempt, ISO 8573.1:2010 | |
| Bowl Material | Polycarbonate | |
| Filter Type | Air Filter | |
| Select all | ||
|---|---|---|
Brand EMERSON ? ASCO | ||
Filtration Size 25μm | ||
Product Type FRL Assembly | ||
Port Size G 1 | ||
Connection Thread Standard G | ||
Drain Type Semi Automatic | ||
Series G653 | ||
Seal Material Nitrile Rubber (NBR) | ||
Maximum Flow Rate 5000L/min | ||
Maximum Operating Pressure 12 bar | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature 50°C | ||
Standards/Approvals ISO 12500, ATEX, CUTR, RoHS Status: Exempt, ISO 8573.1:2010 | ||
Bowl Material Polycarbonate | ||
Filter Type Air Filter | ||
RoHS Status: Exempt
The Asco Particulate Filter offers a large selection of filtering capacities to effectively remove particulate matter and water droplets from compressed air or inert gas systems. It features sintered polyethylene elements combined with a centrifugal separator, providing superior filtration.
Threaded ports allow for individual or modular mounting
Air purity class according to ISO 8573 1 2010
