Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	SKF
	Inside Diameter	35mm
	Product Type	Plummer Block House
	Material	Cast Iron
	Static Load Rating	19kN
	Centre Height	49.2mm
	Mount Hole Size	14 mm
	Length	184mm
	Dynamic Load Rating	30.7kN
	Mount Hole Centre-to-Centre	136.5mm
	Number of Bolts	2
	Series	SYJ
	Standards/Approvals	RoHS, JIS
	Height	99mm
	Bore Type	Tapered
	Limiting Speed	4800rpm

	Select all
	Brand SKF
	Inside Diameter 35mm
	Product Type Plummer Block House
	Material Cast Iron
	Static Load Rating 19kN
	Centre Height 49.2mm
	Mount Hole Size 14 mm
	Length 184mm
	Dynamic Load Rating 30.7kN
	Mount Hole Centre-to-Centre 136.5mm
	Number of Bolts 2
	Series SYJ
	Standards/Approvals RoHS, JIS
	Height 99mm
	Bore Type Tapered
	Limiting Speed 4800rpm

Datasheet - SYJ 40 KF

SKF SYJ Series Plummer Block House, 35mm Inside Diameter, 49.2mm Centre Height - SYJ 40 KF

This plummer Block housing provides bearing support for rotating shafts in industrial assemblies, offering a cast-iron enclosure with a tapered-bore mounting option and an adaptor-sleeve locking system. It is designed for applications requiring a Compact centre height and reliable load transmission while complying with relevant manufacturing standards.

Features and Benefits:

• 4800 r/min limiting speed enables moderately high-speed operation
• 30.7 kN dynamic load rating supports substantial radial loads
• 19 kN static load rating resists heavy stationary forces
• adaptor-sleeve locking ensures precise shaft clamping
• Cast-iron construction offers structural rigidity and vibration damping

Applications

• Suitable for conveyor drive shafts in automation lines
• Ideal for motor-driven assemblies in electrical equipment
• Used with gearboxes in mechanical power transmission systems
• Can be used for rotating components in electronics manufacturing

What bore configuration does this housing use for shaft attachment?

The internal bore is tapered to accept an adaptor sleeve, allowing controlled interference fit and axial positioning without separate locking collars.

What mounting provisions are available for installation?

The unit mounts with two bolts through 14mm holes spaced at 136.5mm centre-to-centre, facilitating secure base attachment.

Which shaft size is compatible with the tapered bore?

The housing accommodates shafts with an effective inside diameter of 35mm when the adaptor sleeve is fitted.

How does the housing height influence alignment tasks?

The centre height of 49.2mm helps determine bearing-line alignment relative to neighbouring components for accurate shaft coupling.

What are the overall envelope dimensions affecting layout?

The cast-iron housing measures 184mm in length and 99mm in external height, information useful for spatial planning and clearance calculations.

SKF SYJ 40 KF Plummer Block House -, 35 mm ID
