SKF SY 513 M Plummer Block House -, 120 mm ID
- RS Stock No.:
- 463-358
- Mfr. Part No.:
- SY 513 M
- Brand:
- SKF
Subtotal (1 unit)*
£81.79
(exc. VAT)
£98.15
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 01 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £81.79 |
*price indicative
- RS Stock No.:
- 463-358
- Mfr. Part No.:
- SY 513 M
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Plummer Block House | |
| Material | Cast Iron | |
| Centre Height | 76.2mm | |
| Mount Hole Size | 22 mm | |
| Length | 258mm | |
| Depth | 65mm | |
| For Use With | ISO Standards, Insert Bearings, Cast Iron | |
| Number of Bolts | 2 | |
| Series | SY | |
| Standards/Approvals | RoHS | |
| Height | 150mm | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Plummer Block House | ||
Material Cast Iron | ||
Centre Height 76.2mm | ||
Mount Hole Size 22 mm | ||
Length 258mm | ||
Depth 65mm | ||
For Use With ISO Standards, Insert Bearings, Cast Iron | ||
Number of Bolts 2 | ||
Series SY | ||
Standards/Approvals RoHS | ||
Height 150mm | ||
The SKF Pillow block housings are designed to accommodate an insert bearing. The cast iron housings are strong, stiff and cost-effective. They are suitable for most applications and can be bolted directly to a support surface.
Accommodate heavy loads in different directions
High degree of stiffness
Narrow design
