TE Connectivity Buchanan Series Pluggable Terminal Block, 2-Contact, 5 mm Pitch, 1-Row

View all Pluggable Terminal Blocks

Subtotal (1 box of 500 units)*

£95.50

(exc. VAT)

£114.50

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 1,000 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Box*
500 +£0.191£95.50

*price indicative

RS Stock No.:
195-2025
Mfr. Part No.:
2350513-2
Brand:
TE Connectivity
Find similar products by selecting one or more attributes.
Select all

Brand

TE Connectivity

Number of Contacts

2

Product Type

Pluggable Terminal Block

Pitch

5mm

Number of Rows

1

Current

16A

Housing Material

Brass

Connector Gender

Male

Minimum Wire Size AWG

26 AWG

Maximum Wire Size AWG

12 AWG

Orientation

Right Angle

Wire Connection Method

Solder

Colour

Green

Voltage

300 V

Depth

8.3mm

Standards/Approvals

RoHS, UL

Series

Buchanan

Width

12 mm

Length

11.6mm

Terminal blocks and strips are insulated connections that fasten two or more wires together and consist of an insulating frame and a clamping system. TE’s Terminal blocks and strips offer a reliable connection with a large variety of technologies and ranges to serve many industrial applications from control to power distribution.

TE Connectivity is expanding its Buchanan portfolio with Push-in clamp termination PCB Connectors to enable tool-less wire insertion of ferruled and unferruled wires. This saves up to 80% installation labor time vs. traditional screw-clamp termination, leading to important cost savings. The design of the PCB Connectors in 3.5 mm and 5.0 mm pitch consists of two-piece plug connectors with mating straight and right angle shrouded headers. TE engineers have designed this product range for use in control system applications to suit high density signal and power applications.
