Jumo 705040 Series Controller for Use with 705021 Series, Analog, Analogue, 24 V dc
- RS Stock No.:
- 278-746
- Mfr. Part No.:
- 705040/36/000
- Brand:
- Jumo
Subtotal (1 unit)*
£284.46
(exc. VAT)
£341.35
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 21 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £284.46 |
*price indicative
- RS Stock No.:
- 278-746
- Mfr. Part No.:
- 705040/36/000
- Brand:
- Jumo
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Jumo | |
Accessory Type | Controller | |
Series | 705040 | |
Number of Inputs | 24 | |
Input Type | Analog | |
Number of Outputs | 16 | |
Output Type | Analogue | |
For Use With | 705021 Series | |
Supply Voltage | 24 V dc | |
Select all | ||
---|---|---|
Brand Jumo | ||
Accessory Type Controller | ||
Series 705040 | ||
Number of Inputs 24 | ||
Input Type Analog | ||
Number of Outputs 16 | ||
Output Type Analogue | ||
For Use With 705021 Series | ||
Supply Voltage 24 V dc | ||
- COO (Country of Origin):
- DE
The Jumo Router module with front-side RJ45 system bus connections achieves decentralization within the automation system, i.e. the input/output modules are distributed across several top-hat rails/control cabinets. There can be a distance of up to 100 m between two router modules or between a router module and a base module or multifunction panel. A maximum of 30 router modules and a maximum of 30 input/output modules are possible in one system. The power supply and operating status of the module are displayed by LEDs. The electrical connection of the power supply of the router module is made on the front via a removable terminal block. The router module does not require configuration. It is integrated into the overall system by the setup program. For special applications such as hot connect, the address of the router module can be set using rotary coding switches. The power supply is DC 24 V +25/-20%.
The module insert can simply be pulled out of the housing at the front for servicing
The housing including the bus board remains mounted on the top hat rail
The housing including the bus board remains mounted on the top hat rail
