Penta Phase Rotation Tester 50 Hz, 60 Hz Max, 400V Max
- RS Stock No.:
- 248-5334
- Mfr. Part No.:
- DR706IVXFR
- Brand:
- Penta
Subtotal (1 unit)*
£332.70
(exc. VAT)
£399.24
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 6 unit(s) shipping from 15 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £332.70 |
*price indicative
Calibration Options:
- Calibration Type:
- RSCAL
- RS Stock No.
- 253-7442
Each
£385.70
(exc. VAT)
£462.84
(inc. VAT)
- RS Stock No.:
- 248-5334
- Mfr. Part No.:
- DR706IVXFR
- Brand:
- Penta
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Penta | |
| Product Type | Phase Rotation Tester | |
| Connection Type | Test Lead | |
| Display Type | LED | |
| Non-Contact | No | |
| Minimum Operating Temperature | -10°C | |
| Maximum Operating Temperature | 55°C | |
| Standards/Approvals | IEC61557-7 | |
| Maximum Frequency | 60Hz | |
| Minimum Voltage | 90V | |
| Minimum Frequency | 50Hz | |
| Maximum Voltage | 400V | |
| Select all | ||
|---|---|---|
Brand Penta | ||
Product Type Phase Rotation Tester | ||
Connection Type Test Lead | ||
Display Type LED | ||
Non-Contact No | ||
Minimum Operating Temperature -10°C | ||
Maximum Operating Temperature 55°C | ||
Standards/Approvals IEC61557-7 | ||
Maximum Frequency 60Hz | ||
Minimum Voltage 90V | ||
Minimum Frequency 50Hz | ||
Maximum Voltage 400V | ||
RoHS Status: Exempt
- COO (Country of Origin):
- FR
The Sibille phase rotation indicator provides a safe, reliable and comfortable phase rotation indication. The unique bright LED display can be read in direct sunlight and it is ergonomically shaped to fit comfortably in the Palm with a range that can be adapted to your needs. The heavy duty waterproof housing (can be used in rain), it can be used in all weathers and it is supplied in a soft case. It comes with replaceable leads with European colour codes and L1/L2/L3 marking (other markings or colours to order).All functions can be operated whilst wearing insulating gloves Indication by chasing green LEDs for clockwise rotation and chasing red LEDs for the counter-clockwise rotation
Voltage range from 90Vac to 400 Vac
AC frequency range from 50 Hz & 60 Hz
Maximum rated voltage of 400 V three phase system
It is 600V CAT III (IP54) or CAT. IV (IP65)
