Phoenix Contact SPTAF Series PCB Terminal Block, 5-Contact, 5 mm Pitch, Wave Soldering Mount, 1 Row
- RS Stock No.:
- 518-862
- Mfr. Part No.:
- 1071049
- Brand:
- Phoenix Contact
Subtotal (1 pack of 65 units)*
£125.71
(exc. VAT)
£150.85
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 01 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £125.71 | £1.934 |
*price indicative
- RS Stock No.:
- 518-862
- Mfr. Part No.:
- 1071049
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | PCB Terminal Block | |
| Number of Contacts | 5 | |
| Pitch | 5mm | |
| Current | 16A | |
| Number of Rows | 1 | |
| Mount Type | Wave Soldering Mount | |
| Housing Material | Polyamide | |
| Minimum Wire Size mm² | 0.2mm² | |
| Maximum Wire Size mm² | 1.5mm² | |
| Minimum Wire Size AWG | 24 AWG | |
| Maximum Wire Size AWG | 16 AWG | |
| Orientation | 45° | |
| Wire Connection Method | Push-in Spring | |
| Colour | Green | |
| Voltage | 137 V | |
| Length | 11mm | |
| Width | 25 mm | |
| Standards/Approvals | IEC 60079-7, IECEx IECEx SEV 19.0026U, ATEX SEV 19 ATEX 0159 U | |
| Series | SPTAF | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type PCB Terminal Block | ||
Number of Contacts 5 | ||
Pitch 5mm | ||
Current 16A | ||
Number of Rows 1 | ||
Mount Type Wave Soldering Mount | ||
Housing Material Polyamide | ||
Minimum Wire Size mm² 0.2mm² | ||
Maximum Wire Size mm² 1.5mm² | ||
Minimum Wire Size AWG 24 AWG | ||
Maximum Wire Size AWG 16 AWG | ||
Orientation 45° | ||
Wire Connection Method Push-in Spring | ||
Colour Green | ||
Voltage 137 V | ||
Length 11mm | ||
Width 25 mm | ||
Standards/Approvals IEC 60079-7, IECEx IECEx SEV 19.0026U, ATEX SEV 19 ATEX 0159 U | ||
Series SPTAF | ||
- COO (Country of Origin):
- PL
The Phoenix Contact PCB Terminal Block is engineered for efficiency and reliability in demanding applications. Tailored for printed circuit boards, this terminal block facilitates a seamless connection via its push-in spring method, allowing for quick installations without the need for tools. With a compact design, it optimises space while ensuring robust performance. Built to withstand high electrical loads, it supports a nominal current of 16 A and features two solder pins per potential, guaranteeing stable, secure connections. Its environmental compliance further enhances its viability for eco-conscious projects, making it a top choice for professionals in diverse sectors, from automation to renewable energy solutions.
Designed for wave soldering applications
Incorporates a finger operated release button for ease of use
Robust construction satisfies stringent safety requirements perfect for explosive environments
Crafted with WEEE/RoHS compliance supporting sustainable practices
Available in a vibrant green colour for easy identification on complex boards
Offers excellent long term stability due to defined contact force
Features linear pinning for straightforward pin layout
Specially designed for both rigid and flexible conductor connections
