Phoenix Contact SMKDSP 1 Series PCB Terminal Block, 6-Contact, 5 mm Pitch, Wave Soldering Mount, 1 Row

View all PCB Terminal Blocks

Subtotal (1 pack of 50 units)*

£90.91

(exc. VAT)

£109.09

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 07 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s)
Per Pack
Per unit*
1 +£90.91£1.818

*price indicative

RS Stock No.:
489-110
Mfr. Part No.:
1733457
Brand:
Phoenix Contact
Find similar products by selecting one or more attributes.
Select all

Brand

Phoenix Contact

Number of Contacts

6

Product Type

PCB Terminal Block

Pitch

5mm

Number of Rows

1

Current

17.5A

Housing Material

Polyamide

Mount Type

Wave Soldering Mount

Minimum Wire Size mm²

0.14mm²

Maximum Wire Size mm²

2.5mm²

Minimum Wire Size AWG

26 AWG

Maximum Wire Size AWG

14 AWG

Orientation

55°

Wire Connection Method

Screw Connection with Tension Sleeve

Colour

Green

Voltage

40 V

Series

SMKDSP 1

Length

13.4mm

Width

30 mm

Standards/Approvals

EN 60695-2-12, EN 60695-2-13, IEC 60112, IEC 60512-3-1:2002-02, IEC 60947-7-4:2019-01, IEC 60999-1:1999-11, UL 94 V0, VDE, CSA, cULus

COO (Country of Origin):
DE
The Phoenix Contact PCB terminal block from the SMKDSP 1.5 series combines high-performance connectivity with a user-friendly design. Tailored for efficient installation, this printed circuit board terminal excels in applications requiring reliable connections and minimal temperature rise. Its robust construction supports a nominal current of 17.5 A and a rated voltage of 400 V, making it suitable for a wide range of electrical systems. With a compact 5 mm pitch and a straightforward screw connection method, this terminal block simplifies the wiring process while ensuring secure conductor connections. Ideal for versatile configurations, the product allows for combinations that suit various positioning needs, ensuring flexibility for assembly in tight spaces. The green housing not only enhances visibility but also assures compliance with strict environmental standards, contributing to sustainable electrical solutions.

Utilises a well-known connection principle for global compatibility

Features a compact design, facilitating efficient circuit board layouts

Supports dual conductor connections for enhanced versatility

Equipped with an integrated testing option for quick diagnostics

Allows angled connections, ideal for multi-row PCB arrangements

Meets stringent environmental regulations, ensuring eco-friendliness

Designed for wave soldering, streamlining assembly processes

Engineered to provide low temperature rise under operational loads
