Phoenix Contact MKDSFW 1 Series PCB Terminal Block, 6-Contact, 3.5 mm Pitch, Wave Soldering Mount, 1 Row

View all PCB Terminal Blocks
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
RS Stock No.:
483-775
Mfr. Part No.:
1868160
Brand:
Phoenix Contact
Find similar products by selecting one or more attributes.
Select all

Brand

Phoenix Contact

Product Type

PCB Terminal Block

Number of Contacts

6

Pitch

3.5mm

Current

12A

Number of Rows

1

Housing Material

Polyamide

Mount Type

Wave Soldering Mount

Minimum Wire Size mm²

0.14mm²

Maximum Wire Size mm²

1.5mm²

Minimum Wire Size AWG

26AWG

Maximum Wire Size AWG

16AWG

Orientation

90°

Colour

Green

Wire Connection Method

Screw Connection with Tension Sleeve

Voltage

160V

Width

22.3mm

Standards/Approvals

cULus Recognised Approval ID: E60425-19770427

Length

11.3mm

Series

MKDSFW 1

COO (Country of Origin):
PL
The Phoenix Contact MKDSFW 1.5/6-3.5 is an advanced printed circuit board terminal designed for reliable connections in various electrical applications. Boasting a low pitch of 3.5 mm, it efficiently accommodates six potential connections within a compact footprint. This terminal block is built to endure the rigours of industry usage, ensuring a robust yet flexible solution for connecting conductors. Its distinguished screw connection design allows for secure and stable attachment of wires, making it a go-to choice for professionals seeking high-quality performance. With a nominal current rating of 12 A and a rated voltage of 160 V, this terminal block is well-suited for a wide range of operational conditions while maintaining exceptional electrical reliability. The MKDSFW series offers practical advantages, including a well-acknowledged connection principle that enhances its versatility across multiple applications.

Constructed for efficient wave soldering, ensuring superior assembly quality

Designed to facilitate the connection of two conductors simultaneously

The green colour coding allows for quick identification and clearer installation

Features a slotted screw head for ease of handling during installation

Adheres to stringent WEEE/RoHS compliance for environmentally conscious operations

Provides exceptional temperature stability, suitable for a wide operating range

Offers enhanced cleaning and sealing possibilities thanks to its stand-off design

Solid pin layout ensures reliable connections under various load conditions

Lightweight design aids in overall product efficiency during assembly
