WAGO 233 Series PCB Terminal Block, 10-Contact, 2.54 mm Pitch, Through Hole, 1 Row
- RS Stock No.:
- 220-792
- Mfr. Part No.:
- 233-410
- Brand:
- WAGO
Subtotal (1 box of 45 units)*
£150.44
(exc. VAT)
£180.53
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 13 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £150.44 | £3.343 |
*price indicative
- RS Stock No.:
- 220-792
- Mfr. Part No.:
- 233-410
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Product Type | PCB Terminal Block | |
| Number of Contacts | 10 | |
| Pitch | 2.54mm | |
| Number of Rows | 1 | |
| Current | 4A | |
| Minimum Wire Size mm² | 0.08mm² | |
| Housing Material | Polyamide 66 | |
| Mount Type | Through Hole | |
| Maximum Wire Size mm² | 0.75mm² | |
| Minimum Wire Size AWG | 28AWG | |
| Maximum Wire Size AWG | 18AWG | |
| Orientation | Parallel, Perpendicular | |
| Colour | Orange | |
| Wire Connection Method | Cage Clamp | |
| Voltage | 150V | |
| Series | 233 | |
| Standards/Approvals | No | |
| Width | 27.7mm | |
| Depth | 12.1mm | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Product Type PCB Terminal Block | ||
Number of Contacts 10 | ||
Pitch 2.54mm | ||
Number of Rows 1 | ||
Current 4A | ||
Minimum Wire Size mm² 0.08mm² | ||
Housing Material Polyamide 66 | ||
Mount Type Through Hole | ||
Maximum Wire Size mm² 0.75mm² | ||
Minimum Wire Size AWG 28AWG | ||
Maximum Wire Size AWG 18AWG | ||
Orientation Parallel, Perpendicular | ||
Colour Orange | ||
Wire Connection Method Cage Clamp | ||
Voltage 150V | ||
Series 233 | ||
Standards/Approvals No | ||
Width 27.7mm | ||
Depth 12.1mm | ||
- COO (Country of Origin):
- CH
The Wago PCB terminal block offers a versatile connection solution for your electronic projects, featuring a compact design that doesn't compromise on performance. Built with CAGE CLAMP technology, it facilitates quick and reliable connections, ensuring maximum stability and reliability even in demanding applications.
Constructed from durable polyamide for reliable insulation
Meets stringent environmental requirements with a wide temperature range
Compliant with RoHS standards ensuring eco friendly use
Includes diverse approval certifications for extended application versatility
