Samtec MMS Series Vertical Through Hole PCB Socket, 34-Contact, 2 Row, 2 mm Pitch Solder

View all PCB Sockets
Bulk discount available

Subtotal (1 unit)*

£7.17

(exc. VAT)

£8.60

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 17 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 - 4£7.17
5 +£6.39

*price indicative

RS Stock No.:
208-8920
Mfr. Part No.:
MMS-117-02-L-DV
Brand:
Samtec
Find similar products by selecting one or more attributes.
Select all

Brand

Samtec

Product Type

PCB Socket

Number of Contacts

34

Sub Type

Board-to-Board

Number of Rows

2

Current

3.9A

Pitch

2mm

Housing Material

Liquid Crystal Polymer

Termination Type

Solder

Mount Type

Through Hole

Orientation

Vertical

Connector System

Board-to-Board

Series

MMS

Minimum Operating Temperature

-55°C

Contact Plating

Gold

Maximum Operating Temperature

125°C

Contact Material

Phosphor Bronze

Standards/Approvals

RoHS

The Samtec MMS is a socket strip for through-hole termination. Available in single row configuration, this 2.00 mm pitch connector with 34 position which uses the Tiger Claw dual wipe contact system to deliver power up to 3.9 Amps per pin.

Phosphor bronze contact material

Black LCP insulating material
