Samtec FS5 Series Vertical Through Hole PCB Socket, 30-Contact, 2 Row, 0.5 mm Pitch Solder
- RS Stock No.:
- 196-9890
- Mfr. Part No.:
- FS5-15-04.0-L-DV-TH-TR
- Brand:
- Samtec
Bulk discount available
Subtotal (1 reel of 350 units)*
£1,591.45
(exc. VAT)
£1,909.60
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 02 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 350 - 350 | £4.547 | £1,591.45 |
| 700 + | £4.197 | £1,468.95 |
*price indicative
- RS Stock No.:
- 196-9890
- Mfr. Part No.:
- FS5-15-04.0-L-DV-TH-TR
- Brand:
- Samtec
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Samtec | |
| Number of Contacts | 30 | |
| Product Type | PCB Socket | |
| Number of Rows | 2 | |
| Sub Type | Board-to-Board | |
| Current | 1.8A | |
| Pitch | 0.5mm | |
| Termination Type | Solder | |
| Housing Material | Liquid Crystal Polymer | |
| Mount Type | Through Hole | |
| Orientation | Vertical | |
| Connector System | Board-to-Board | |
| Series | FS5 | |
| Minimum Operating Temperature | -55°C | |
| Row Pitch | 6.65mm | |
| Contact Plating | Gold | |
| Maximum Operating Temperature | 125°C | |
| Contact Material | Beryllium Copper Alloy | |
| Standards/Approvals | RoHS | |
| Select all | ||
|---|---|---|
Brand Samtec | ||
Number of Contacts 30 | ||
Product Type PCB Socket | ||
Number of Rows 2 | ||
Sub Type Board-to-Board | ||
Current 1.8A | ||
Pitch 0.5mm | ||
Termination Type Solder | ||
Housing Material Liquid Crystal Polymer | ||
Mount Type Through Hole | ||
Orientation Vertical | ||
Connector System Board-to-Board | ||
Series FS5 | ||
Minimum Operating Temperature -55°C | ||
Row Pitch 6.65mm | ||
Contact Plating Gold | ||
Maximum Operating Temperature 125°C | ||
Contact Material Beryllium Copper Alloy | ||
Standards/Approvals RoHS | ||
The Samtec FS5-15-04.0-L-DV-TH-TR is a FS5 series high speed floating contact system.IT has Double row design up to 60 floating contacts.
Insulator material: black liquid crystal polymer
Weld tab: phosphor bronze
Operating temp range:-55°C to +125°C
