Samtec SSW Series Right Angle Through Hole Mount PCB Socket, 6-Contact, 1-Row, 2.54mm Pitch, Solder Termination
- RS Stock No.:
- 180-1015
- Mfr. Part No.:
- SSW-106-02-T-S-RA
- Brand:
- Samtec
20 In stock - FREE next working day delivery available
Added
Price Each (In a Pack of 10)
£0.74
(exc. VAT)
£0.89
(inc. VAT)
| Units | Per unit | Per Pack* |
| 10 - 40 | £0.74 | £7.40 |
| 50 - 90 | £0.664 | £6.64 |
| 100 - 190 | £0.601 | £6.01 |
| 200 - 490 | £0.549 | £5.49 |
| 500 + | £0.507 | £5.07 |
| *price indicative | ||
- RS Stock No.:
- 180-1015
- Mfr. Part No.:
- SSW-106-02-T-S-RA
- Brand:
- Samtec
Technical Reference
Legislation and Compliance
Product Details
This solder tail socket strip features high retention, cost-effective Tiger Buy™ contacts with surface mount or through-hole tails in single, double and triple row options. Straight or right-angle pins are available for standard insertion force or low insertion force to mate with .025” square post terminals.
Application: Single, double and triple row up to 150 pins
Contact System: Tiger Buy™
Orientation: Vertical, right-angle
Pitch: .100" (2.54 mm)
Special Features: Standard and low insertion force contacts with standard solder tails
Termination: Through-hole, surface mount
Contact System: Tiger Buy™
Orientation: Vertical, right-angle
Pitch: .100" (2.54 mm)
Special Features: Standard and low insertion force contacts with standard solder tails
Termination: Through-hole, surface mount
Specifications
Attribute | Value |
|---|---|
| Number of Contacts | 6 |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Type | Socket Strip |
| Mounting Type | Through Hole |
| Body Orientation | Right Angle |
| Termination Method | Solder |
| Current Rating | 4.7A |
| Voltage Rating | 465 V , 655 V |
| Series | SSW |
| Contact Material | Bronze |
| Contact Plating | Tin |
