Molex 52418 Series Right Angle Board PCB Socket, 3-Contact, 1 Row, 2 mm Pitch Solder
- RS Stock No.:
- 506-067
- Mfr. Part No.:
- 52418-0310
- Brand:
- Molex
Subtotal (1 tray of 1000 units)*
£142.60
(exc. VAT)
£171.12
(inc. VAT)
Add 1 tray to get free delivery
Temporarily out of stock
- Shipping from 10 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tray(s) | Per Tray | Per unit* |
|---|---|---|
| 1 + | £142.60 | £0.143 |
*price indicative
- RS Stock No.:
- 506-067
- Mfr. Part No.:
- 52418-0310
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Number of Contacts | 3 | |
| Product Type | PCB Socket | |
| Number of Rows | 1 | |
| Sub Type | PCB Receptacle | |
| Pitch | 2mm | |
| Current | 1.5A | |
| Housing Material | Polyester | |
| Termination Type | Solder | |
| Mount Type | Board | |
| Orientation | Right Angle | |
| Stacking Height | 3.95mm | |
| Voltage | 125 V | |
| Series | 52418 | |
| Minimum Operating Temperature | -40°C | |
| Row Pitch | 2mm | |
| Contact Material | Phosphor Bronze | |
| Maximum Operating Temperature | 105°C | |
| Contact Plating | Tin | |
| Standards/Approvals | UL E29179 | |
| Select all | ||
|---|---|---|
Brand Molex | ||
Number of Contacts 3 | ||
Product Type PCB Socket | ||
Number of Rows 1 | ||
Sub Type PCB Receptacle | ||
Pitch 2mm | ||
Current 1.5A | ||
Housing Material Polyester | ||
Termination Type Solder | ||
Mount Type Board | ||
Orientation Right Angle | ||
Stacking Height 3.95mm | ||
Voltage 125 V | ||
Series 52418 | ||
Minimum Operating Temperature -40°C | ||
Row Pitch 2mm | ||
Contact Material Phosphor Bronze | ||
Maximum Operating Temperature 105°C | ||
Contact Plating Tin | ||
Standards/Approvals UL E29179 | ||
- COO (Country of Origin):
- MY
The TE Connectivity 2.00mm Pitch Board-to-Board Receptacle offers an innovative solution for compact electronic assemblies. Its right-angle design maximises space efficiency, making it ideal for applications requiring minimal dimensions without sacrificing performance. With a robust construction and a friction lock feature, this receptacle guarantees secure connections even in the most demanding environments. Designed to accommodate three circuits, it ensures reliable signal transmission for a variety of board-to-board applications. While currently not recommended for new design projects, it still serves as a dependable component for existing setups, delivering quality and durability for your electronic needs.
Compact design enables efficient use of space in electronics
Friction lock secures connections under challenging conditions
Robust construction delivers enhanced durability and longevity
Supports multiple applications, catering to diverse industry needs
Right-angle orientation simplifies layout and installation
Designed to work effectively within a temperature range of -40° to +105°C
Natural resin colour aligns with aesthetic requirements without compromise
