Samtec EW Series Straight Through Hole Pin Header, 50 Contact(s), 2.54mm Pitch, 1 Row(s), Unshrouded
- RS Stock No.:
- 277-9742
- Mfr. Part No.:
- EW5012LS500
- Brand:
- Samtec
124 In stock - FREE next working day delivery available
64 available from Europe for delivery within 1 working day(s).
Price Each (In a Bag of 4)
£5.018
(exc. VAT)
£6.022
(inc. VAT)
Units | Per unit | Per Bag* |
---|---|---|
4 - 76 | £5.018 | £20.072 |
80 - 296 | £4.165 | £16.66 |
300 - 1196 | £3.508 | £14.032 |
1200 - 2396 | £3.26 | £13.04 |
2400 + | £3.01 | £12.04 |
*price indicative
- RS Stock No.:
- 277-9742
- Mfr. Part No.:
- EW5012LS500
- Brand:
- Samtec
Technical Reference
Legislation and Compliance
Product Details
Samtec Pin Header, Board-to-Board Connector System, Gold-Plated Contacts - EW Series - EW5012LS500
Securely link your PCBs in a flash using this pin header from Samtec. It has a single row of 50 metallic contact pins to create a connection between your board and a second PCB or female socket. Data flows smoothly between the connecting pins, as they're made from highly conductive and corrosion-resistant gold-plated phosphor bronze. A 3A current rating makes this component safe for use in low-power installations. You can install this unit in a jiffy using through-hole mounting.
Features & Benefits
• Unshrouded construction means there's no extra casing to deal with
• Pitch of 2.54mm for broad compatibility with standard PCB setups
• Glass-filled polyester insulation is resistant to heat and wear
• Performs reliably in challenging conditions, thanks to a wide operating temperature range between -65°C and +125°C
• Pitch of 2.54mm for broad compatibility with standard PCB setups
• Glass-filled polyester insulation is resistant to heat and wear
• Performs reliably in challenging conditions, thanks to a wide operating temperature range between -65°C and +125°C
Applications
• Telecommunications
• Electronics manufacturing
• Satellite navigation systems
• Electronics manufacturing
• Satellite navigation systems
What's this pin header's orientation?
The header is vertically oriented, which means it allows you to stack PCBs on top of one another to create a board-to-board system.
What size are the pins?
The tail pin length is 8.38mm and the mating pin length is 5.08mm, making this header a compact choice for crowded boards.
2.54mm Board to Board and Wire to Board - Samtec
Specifications
Attribute | Value |
---|---|
Series | EW |
Pitch | 2.54mm |
Number of Contacts | 50 |
Number of Rows | 1 |
Body Orientation | Straight |
Shrouded/Unshrouded | Unshrouded |
Mounting Type | Through Hole |
Connector System | Board to Board |
Termination Method | Solder |
Contact Plating | Gold |
Contact Material | Phosphor Bronze |
Current Rating | 3.0A |
Tail Pin Length | 8.38mm |
Mating Pin Length | 5.08mm |
Gender | Male |
