Samtec SHF Series Straight PCB Header, 26 Contact(s), 1.27mm Pitch, 2 Row(s), Shrouded
- RS Stock No.:
- 208-9407
- Mfr. Part No.:
- SHF-113-01-L-D-SM-LC
- Brand:
- Samtec
50 In stock - FREE next working day delivery available
Added
Price Each (In a Tube of 25)
£3.959
(exc. VAT)
£4.751
(inc. VAT)
| Units | Per unit | Per Tube* |
| 25 - 100 | £3.959 | £98.975 |
| 125 - 225 | £3.73 | £93.25 |
| 250 + | £3.528 | £88.20 |
| *price indicative | ||
- RS Stock No.:
- 208-9407
- Mfr. Part No.:
- SHF-113-01-L-D-SM-LC
- Brand:
- Samtec
Technical Reference
Legislation and Compliance
Product Details
The Samtec 1.27 mm SHF series is a shrouded PCB mounting terminal strip for use with FFSD flat ribbon and FFTP twisted pair cable assemblies. It has 26 contact using surface mount.
Black LCP insulator material
Temperature range -55 to 125 °C
Temperature range -55 to 125 °C
Specifications
Attribute | Value |
|---|---|
| Series | SHF |
| Pitch | 1.27mm |
| Number of Contacts | 26 |
| Number of Rows | 2 |
| Body Orientation | Straight |
| Shrouded/Unshrouded | Shrouded |
