Samtec TSM Series Vertical Surface Mount Pin Header, 36 Contact(s), 2.54mm Pitch, 2 Row(s), Unshrouded
- RS Stock No.:
- 208-6464
- Mfr. Part No.:
- TSM-118-01-T-DV
- Brand:
- Samtec
2 In stock - FREE next working day delivery available
Added
Price Each (In a Pack of 2)
£2.86
(exc. VAT)
£3.43
(inc. VAT)
| Units | Per unit | Per Pack* |
| 2 - 8 | £2.86 | £5.72 |
| 10 + | £2.56 | £5.12 |
| *price indicative | ||
- RS Stock No.:
- 208-6464
- Mfr. Part No.:
- TSM-118-01-T-DV
- Brand:
- Samtec
Technical Reference
Legislation and Compliance
Product Details
The Samtec TSM series SMT board-to-board square post header terminal strip with a 2.54mm pitch, which has 36 contact, a black liquid crystal polymer insulator and phosphor bronze terminal. It used matte tin on tail and has double row with vertical body or
Operating temperature range -55°C to +125°C
Voltage Rating 475 VAC
Voltage Rating 475 VAC
Specifications
Attribute | Value |
|---|---|
| Series | TSM |
| Pitch | 2.54mm |
| Number of Contacts | 36 |
| Number of Rows | 2 |
| Body Orientation | Vertical |
| Shrouded/Unshrouded | Unshrouded |
| Mounting Type | Surface Mount |
