Samtec TSM Series Horizontal Surface Mount Pin Header, 2 Contact(s), 2.54mm Pitch, 1 Row(s), Unshrouded
- RS Stock No.:
- 200-1529
- Mfr. Part No.:
- TSM-102-01-L-SH-P-TR
- Brand:
- Samtec
6 In stock - FREE next working day delivery available
Price Each (On a Reel of 400)
£0.649
(exc. VAT)
£0.779
(inc. VAT)
Units | Per unit | Per Reel* |
|---|---|---|
| 400 - 400 | £0.649 | £259.60 |
| 800 + | £0.559 | £223.60 |
*price indicative
- RS Stock No.:
- 200-1529
- Mfr. Part No.:
- TSM-102-01-L-SH-P-TR
- Brand:
- Samtec
Technical Reference
Legislation and Compliance
Product Details
The Samtec TSM series is a surface mount terminal strip. Insulating material used is of Black liquid crystal polymer. Terminals are of phosphor bronze. There are total 2 no. of contacts.
Plating used : Au or Sn over 50 μ" (1.27 μm) Ni
Operating temp range: -55 °C to +105 °C with Tin
Operating temp range: -55 °C to +105 °C with Tin
-55 °C to +125 °C with Gold
It is RoHS Compliant
It is RoHS Compliant
Specifications
Attribute | Value |
|---|---|
| Series | TSM |
| Pitch | 2.54mm |
| Number of Contacts | 2 |
| Number of Rows | 1 |
| Body Orientation | Horizontal |
| Shrouded/Unshrouded | Unshrouded |
| Mounting Type | Surface Mount |
