Samtec TSM Series Straight Surface Mount Pin Header, 2 Contact(s), 2.54mm Pitch, 1 Row(s), Unshrouded
- RS Stock No.:
- 180-2475
- Mfr. Part No.:
- TSM-102-01-T-SV-P-TR
- Brand:
- Samtec
Available to back order for despatch 29/07/2024
Price Each (On a Reel of 325)
£0.416
(exc. VAT)
£0.499
(inc. VAT)
Units | Per unit | Per Reel* |
---|---|---|
325 + | £0.416 | £135.20 |
*price indicative
- RS Stock No.:
- 180-2475
- Mfr. Part No.:
- TSM-102-01-T-SV-P-TR
- Brand:
- Samtec
Technical Reference
Legislation and Compliance
Product Details
Application: Choice of standard post heights provide solutions to mate with any Samtec socket
Contact System: .025" (0.635 mm) square post
Orientation: Vertical, horizontal
Pitch: .100" (2.54 mm)
Special Features: Designed specifically for surface mount applications with many options to facilitate processing
Termination: Surface mount, mixed technology
Contact System: .025" (0.635 mm) square post
Orientation: Vertical, horizontal
Pitch: .100" (2.54 mm)
Special Features: Designed specifically for surface mount applications with many options to facilitate processing
Termination: Surface mount, mixed technology
Specifications
Attribute | Value |
---|---|
Series | TSM |
Pitch | 2.54mm |
Number of Contacts | 2 |
Number of Rows | 1 |
Body Orientation | Straight |
Shrouded/Unshrouded | Unshrouded |
Mounting Type | Surface Mount |
Connector System | Board to Board |
Termination Method | Solder |
Contact Plating | Tin |
Contact Material | Phosphor Bronze |
Current Rating | 4.0A |
Mating Pin Length | 5.84mm |
Voltage Rating | 475.0 V |
