Samtec HPM Series Right Angle Through Hole Pin Header, 6 Contact(s), 5.08mm Pitch, 1 Row(s), Unshrouded
- RS Stock No.:
- 180-0623
- Mfr. Part No.:
- HPM-06-02-T-S-RA
- Brand:
- Samtec
Available to back order for despatch 29/05/2024
Added
Price Each (In a Pack of 5)
£2.038
(exc. VAT)
£2.446
(inc. VAT)
| Units | Per unit | Per Pack* |
| 5 - 20 | £2.038 | £10.19 |
| 25 - 45 | £1.876 | £9.38 |
| 50 - 95 | £1.734 | £8.67 |
| 100 - 245 | £1.612 | £8.06 |
| 250 + | £1.506 | £7.53 |
| *price indicative | ||
- RS Stock No.:
- 180-0623
- Mfr. Part No.:
- HPM-06-02-T-S-RA
- Brand:
- Samtec
Technical Reference
Legislation and Compliance
Product Details
Contact System: .045" (1.14 mm) square post
Orientation: Vertical, right-angle
Pitch: .200" (5.08 mm)
Termination: Through-hole, surface mount
Orientation: Vertical, right-angle
Pitch: .200" (5.08 mm)
Termination: Through-hole, surface mount
Specifications
Attribute | Value |
|---|---|
| Series | HPM |
| Pitch | 5.08mm |
| Number of Contacts | 6 |
| Number of Rows | 1 |
| Body Orientation | Right Angle |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board to Board |
| Mounting Type | Through Hole |
| Termination Method | Solder |
| Contact Plating | Tin |
| Contact Material | Copper Alloy |
| Tail Pin Length | 4.57mm |
| Mating Pin Length | 13.21mm |
| Voltage Rating | 1.2 kV , 850.0 V ac |
