Samtec QTS Series Right Angle Surface Mount PCB Header, 150 Contact(s), 0.64mm Pitch, 2 Row(s), Shrouded
- RS Stock No.:
- 158-5658
- Mfr. Part No.:
- QTS-075-01-F-D-RA-WT
- Brand:
- Samtec
Bulk discount available
Subtotal (1 tray of 12 units)*
£187.176
(exc. VAT)
£224.616
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 12 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tray* |
|---|---|---|
| 12 - 108 | £15.598 | £187.18 |
| 120 - 588 | £12.635 | £151.62 |
| 600 - 1188 | £12.292 | £147.50 |
| 1200 - 5988 | £11.963 | £143.56 |
| 6000 + | £11.668 | £140.02 |
*price indicative
- RS Stock No.:
- 158-5658
- Mfr. Part No.:
- QTS-075-01-F-D-RA-WT
- Brand:
- Samtec
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Samtec | |
| Series | QTS | |
| Pitch | 0.64mm | |
| Number of Contacts | 150 | |
| Number of Rows | 2 | |
| Body Orientation | Right Angle | |
| Shrouded/Unshrouded | Shrouded | |
| Connector System | Board to Board | |
| Mounting Type | Surface Mount | |
| Termination Method | Solder | |
| Contact Plating | Gold | |
| Contact Material | Phosphor Bronze | |
| Current Rating | 2.0 A, 15.7A | |
| Voltage Rating | 275.0 V | |
| Select all | ||
|---|---|---|
Brand Samtec | ||
Series QTS | ||
Pitch 0.64mm | ||
Number of Contacts 150 | ||
Number of Rows 2 | ||
Body Orientation Right Angle | ||
Shrouded/Unshrouded Shrouded | ||
Connector System Board to Board | ||
Mounting Type Surface Mount | ||
Termination Method Solder | ||
Contact Plating Gold | ||
Contact Material Phosphor Bronze | ||
Current Rating 2.0 A, 15.7A | ||
Voltage Rating 275.0 V | ||
0.635 mm Q Strip® High-Speed Ground Plane Terminal Strip, Right-Angle
0.635 mm (.025") pitch
Dual sourced by TE Connectivity as the MICTOR SB
Guide post option
Up to 200 positions
Up to 4.5 GHz / 9 Gbps
