Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Samtec
	Series	TMM
	Product Type	Pin Header
	Pitch	2mm
	Current	3.2A
	Number of Contacts	16
	Housing Material	Liquid Crystal Polymer
	Number of Rows	2
	Orientation	Straight
	Shrouded/Unshrouded	Unshrouded
	Connector System	Board-to-Board, Wire-to-Board
	Mount Type	Through Hole
	Contact Material	Phosphor Bronze
	Contact Plating	Gold
	Minimum Operating Temperature	-55°C
	Termination Type	Solder
	Maximum Operating Temperature	125°C
	Contact Gender	Male
	Standards/Approvals	No
	Voltage	281 V

	Select all
	Brand Samtec
	Series TMM
	Product Type Pin Header
	Pitch 2mm
	Current 3.2A
	Number of Contacts 16
	Housing Material Liquid Crystal Polymer
	Number of Rows 2
	Orientation Straight
	Shrouded/Unshrouded Unshrouded
	Connector System Board-to-Board, Wire-to-Board
	Mount Type Through Hole
	Contact Material Phosphor Bronze
	Contact Plating Gold
	Minimum Operating Temperature -55°C
	Termination Type Solder
	Maximum Operating Temperature 125°C
	Contact Gender Male
	Standards/Approvals No
	Voltage 281 V

2.00 mm Low Profile Terminal Strip

Application: Industry's largest variety of low profile pin counts, terminal lengths and options

Contact System: .020" (0.50 mm) square post

Orientation: Vertical, right-angle

Pitch: 2.00 mm (.0787")

Special Features: FleXYZ™ provides design flexibility in all three axes up to four rows wide and 200 pins

Termination: Through-hole, surface mount

Samtec TMM Series Straight Through Hole Pin Header, 16 Contact(s), 2 mm Pitch, 2 Row, Unshrouded
