Molex 42375 Series Vertical PCB PCB Header, 7 Contact(s), 2.54 mm Pitch, 1 Row(s), Unshrouded
- RS Stock No.:
- 685-039
- Mfr. Part No.:
- 22-28-5070
- Brand:
- Molex
Subtotal (1 bag of 1000 units)*
£202.20
(exc. VAT)
£242.64
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 07 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Bag(s) | Per Bag | Per unit* |
|---|---|---|
| 1 + | £202.20 | £0.202 |
*price indicative
- RS Stock No.:
- 685-039
- Mfr. Part No.:
- 22-28-5070
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Series | 42375 | |
| Product Type | PCB Header | |
| Current | 4A | |
| Pitch | 2.54mm | |
| Housing Material | Nylon | |
| Number of Contacts | 7 | |
| Number of Rows | 1 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Unshrouded | |
| Mount Type | PCB | |
| Contact Material | Brass | |
| Contact Plating | Gold | |
| Termination Type | Solder | |
| Row Pitch | 2.54mm | |
| Tail Pin Length | 3.05mm | |
| Standards/Approvals | RoHS | |
| Voltage | 500 V | |
| Select all | ||
|---|---|---|
Brand Molex | ||
Series 42375 | ||
Product Type PCB Header | ||
Current 4A | ||
Pitch 2.54mm | ||
Housing Material Nylon | ||
Number of Contacts 7 | ||
Number of Rows 1 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Unshrouded | ||
Mount Type PCB | ||
Contact Material Brass | ||
Contact Plating Gold | ||
Termination Type Solder | ||
Row Pitch 2.54mm | ||
Tail Pin Length 3.05mm | ||
Standards/Approvals RoHS | ||
Voltage 500 V | ||
- COO (Country of Origin):
- IN
The Molex KK 254 Breakaway Header is a highly versatile connector designed for efficient board-to-board and wire-to-board applications. This active component features a vertical orientation and accommodates up to seven circuits, making it ideal for compact electronic designs that require reliable signal integrity. Crafted with tin-plated contacts and kinked PC tails, this header ensures secure mating and optimal performance, while its robust construction using high-temperature thermoplastic guarantees durability. The compatibility with various terminal housings, receptacles, and crimp housings further enhances its functionality, making it a preferred choice for engineers seeking dependable connectivity solutions in modern PCB layouts.
Accommodates up to seven circuits for flexible connectivity options
Vertical orientation optimises space in compact electronic designs
Tin plating enhances the durability and reliability of electrical contacts
Kinked PC tails provide secure mating and improve thermal performance
High temperature thermoplastic construction ensures longevity in demanding environments
Compatible with a range of terminal and receptacle housings for versatile applications
Designed for board to board and wire to board configurations, facilitating diverse connectivity
Meets flammability standards of 94V0 for increased safety
Low profile design allows for efficient integration into multi layer printed circuit boards
