Molex 42375 Series Vertical PCB PCB Header, 8 Contact(s), 2.54 mm Pitch, 1 Row(s), Unshrouded
- RS Stock No.:
- 684-682
- Mfr. Part No.:
- 22-28-4088
- Brand:
- Molex
Subtotal (1 pack of 400 units)*
£225.06
(exc. VAT)
£270.07
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 22 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £225.06 | £0.563 |
*price indicative
- RS Stock No.:
- 684-682
- Mfr. Part No.:
- 22-28-4088
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Series | 42375 | |
| Product Type | PCB Header | |
| Pitch | 2.54mm | |
| Current | 4A | |
| Housing Material | Nylon | |
| Number of Contacts | 8 | |
| Number of Rows | 1 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Unshrouded | |
| Mount Type | PCB | |
| Contact Plating | Gold | |
| Contact Material | Brass | |
| Termination Type | Solder | |
| Row Pitch | 2.54mm | |
| Tail Pin Length | 3.05mm | |
| Standards/Approvals | RoHS | |
| Voltage | 500 V | |
| Select all | ||
|---|---|---|
Brand Molex | ||
Series 42375 | ||
Product Type PCB Header | ||
Pitch 2.54mm | ||
Current 4A | ||
Housing Material Nylon | ||
Number of Contacts 8 | ||
Number of Rows 1 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Unshrouded | ||
Mount Type PCB | ||
Contact Plating Gold | ||
Contact Material Brass | ||
Termination Type Solder | ||
Row Pitch 2.54mm | ||
Tail Pin Length 3.05mm | ||
Standards/Approvals RoHS | ||
Voltage 500 V | ||
- COO (Country of Origin):
- IN
The Molex KK 254 Breakaway Header designed to provide a reliable connection in various applications, including board-to-board, signal, and wire-to-board setups. With its vertical orientation and 8 circuits, this header is engineered for optimal performance, featuring 0.76μm gold selective plating that enhances contact reliability. It boasts a durable design with up to 100 mating cycles and operates effectively within a voltage range of 500V and a maximum current of 4.0A per contact. Ideal for high-temperature environments, the header is constructed from high-temperature thermoplastic resin, ensuring longevity and robustness in demanding applications.
Vertical orientation supports space efficient installations
Eight circuits enable versatile connectivity options for various applications
Constructed with high temperature thermoplastic for durability in extreme conditions
Gold selective plating ensures optimal conductivity and reduces oxidation
Meets strict flammability standards for enhanced safety
Designed for easy integration with multiple mating components, enhancing compatibility
Supports through hole termination style, allowing for straightforward PCB assembly
Lightweight design minimises overall product weight
Backed by compliance with EU RoHS regulations, ensuring environmental safety
