Molex 70280 Series Vertical PCB Mount PCB Header, 4 Contact(s), 2.54mm Pitch, 2 Row(s), Unshrouded
- RS Stock No.:
- 684-565
- Mfr. Part No.:
- 10-97-7046
- Brand:
- Molex
Subtotal (1 bag of 400 units)*
£183.56
(exc. VAT)
£220.27
(inc. VAT)
Stock information currently inaccessible
Bag(s) | Per Bag | Per unit* |
|---|---|---|
| 1 + | £183.56 | £0.459 |
*price indicative
- RS Stock No.:
- 684-565
- Mfr. Part No.:
- 10-97-7046
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Series | 70280 | |
| Pitch | 2.54mm | |
| Number of Contacts | 4 | |
| Number of Rows | 2 | |
| Body Orientation | Vertical | |
| Shrouded/Unshrouded | Unshrouded | |
| Mounting Type | PCB Mount | |
Select all | ||
|---|---|---|
Brand Molex | ||
Series 70280 | ||
Pitch 2.54mm | ||
Number of Contacts 4 | ||
Number of Rows 2 | ||
Body Orientation Vertical | ||
Shrouded/Unshrouded Unshrouded | ||
Mounting Type PCB Mount | ||
- COO (Country of Origin):
- MY
The Molex C-Grid Breakaway Header designed to facilitate reliable connections in a variety of electronic applications. This dual-row, vertical connector features a 2.54mm pitch and supports up to four circuits, making it ideal for board-to-board and wire-to-board configurations. With high temperature resistance and durable materials, this component ensures excellent performance in demanding environments. The selective gold plating enhances conductivity, while the tin-plated PC tail provides robust connectivity. Designed for ease of use, it integrates seamlessly into numerous PCB layouts and configurations, embodying both versatility and reliability in performance. The C-Grid series exemplifies engineering excellence and innovation, ensuring compliance with industry standards while meeting specific application needs.
Vertical orientation allows efficient use of PCB space
Durability rated for 50 mating cycles supports long-term use
Black resin colours provides a sleek, professional appearance
Wide operating temperature range (-40° to +105°C) accommodates diverse applications
Durability rated for 50 mating cycles supports long-term use
Black resin colours provides a sleek, professional appearance
Wide operating temperature range (-40° to +105°C) accommodates diverse applications
