Samtec MEC2 Series Vertical Surface PCB Header, 10 Contact(s), 2 mm Pitch, 2 Row(s), Shrouded

View all PCB Headers
Bulk discount available

Subtotal (1 unit)*

£4.14

(exc. VAT)

£4.97

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 26 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 - 9£4.14
10 - 24£3.81
25 +£3.44

*price indicative

RS Stock No.:
637-597
Mfr. Part No.:
MEC2-05-01-L-DV-WT-K-TR
Brand:
Samtec
Find similar products by selecting one or more attributes.
Select all

Brand

Samtec

Product Type

PCB Header

Series

MEC2

Pitch

2mm

Current

3.5A

Number of Contacts

10

Housing Material

Black LCP, Liquid Crystal Polymer

Number of Rows

2

Orientation

Vertical

Shrouded/Unshrouded

Shrouded

Mount Type

Surface

Contact Plating

Gold, Tin

Contact Material

Beryllium Copper Alloy

Termination Type

Vertical Surface Mount

Minimum Operating Temperature

-55°C

Row Pitch

2mm

Maximum Operating Temperature

125°C

Standards/Approvals

RoHS

Voltage

332 V

The Samtec Pitch mini edge card connector designed for high-density board-to-board applications. It features a vertical, dual-row configuration and is optimized for .062" (1.57 mm) thick cards, offering reliable signal integrity in compact layouts.

Vertical mount with surface mount termination

Current rating up to 3.5A per contact

Includes board guide and pick and place features
