MPN

RS PRO XY2500 Series Straight Through Hole PCB Header, 4 Contact(s), 3.81 mm Pitch, 1 Row, Shrouded

RS Stock No.:: 631-108
Brand:: RS PRO

RS PRO XY2500 Series Straight Through Hole PCB Header, 4 Contact(s), 3.81 mm Pitch, 1 Row, Shrouded

Subtotal (1 bag of 10 units)*

£55.45

(exc. VAT)

£66.54

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

Plus 50 unit(s) shipping from 17 June 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Bag(s)	Per Bag	Per unit*
1 +	£55.45	£5.545

*price indicative

RS Stock No.:: 631-108
Brand:: RS PRO

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	RS PRO
	Product Type	PCB Header
	Series	XY2500
	Pitch	3.81mm
	Current	8A
	Number of Contacts	4
	Housing Material	PA66
	Number of Rows	1
	Orientation	Straight
	Shrouded/Unshrouded	Shrouded
	Mount Type	Through Hole
	Connector System	Board-to-Board, Board-to-Wire
	Contact Plating	Nickel
	Contact Material	Phosphor Bronze
	Minimum Operating Temperature	-40°C
	Termination Type	Screw
	Maximum Operating Temperature	105°C
	Contact Gender	Male
	Standards/Approvals	ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL
	Voltage	300V

	Select all
	Brand RS PRO
	Product Type PCB Header
	Series XY2500
	Pitch 3.81mm
	Current 8A
	Number of Contacts 4
	Housing Material PA66
	Number of Rows 1
	Orientation Straight
	Shrouded/Unshrouded Shrouded
	Mount Type Through Hole
	Connector System Board-to-Board, Board-to-Wire
	Contact Plating Nickel
	Contact Material Phosphor Bronze
	Minimum Operating Temperature -40°C
	Termination Type Screw
	Maximum Operating Temperature 105°C
	Contact Gender Male
	Standards/Approvals ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL
	Voltage 300V

COO (Country of Origin):: CN

RS PRO 4-Pin Shrouded PCB Header, 8 A, 3.81 mm Pitch

This RS PRO PCB Header is designed for reliable electrical connections in various industrial applications. With a robust construction and a shrouded design, it ensures secure and efficient connectivity. Ideal for board-to-board and board-to-wire systems, it supports a current rating of up to 8 A, making it suitable for demanding environments.

Features and Benefits

Board-to-Board and Board-to-Wire Compatibility: Versatile use in different connection systems
Male Contact Gender: Ensures a secure and stable connection
Phosphor Bronze Contacts: Offers excellent conductivity and durability
Nickel Plating: Provides corrosion resistance for long-lasting performance
Current Rating of 8 A: Suitable for high-power applications
PA66 Housing Material: High resistance to heat and chemicals
Operating Temperature Range -40 °C to 105 °C: Suitable for extreme environments
Through Hole Mount Type: Ensures robust mechanical stability
Shrouded Design: Protects contacts and enhances connection reliability

Applications

Industrial automation
Consumer electronics
Telecommunications
Automotive systems

Additional Information

Complies with ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL standards
Screw termination type for secure wiring
Voltage rating of 300 V for high-voltage applications

Why RS PRO?

RS PRO is the own brand of RS, offering professional quality products and solutions across all industries and technologies. Our product range is rigorously tested, inspected, and audited against demanding international standards to provide you with industrial-grade quality, at the right price. Making RS PRO your smart choice.
