Phoenix Contact MC Series Wave Soldering Mount PCB Header, 5 Contact(s), 3.5 mm Pitch, 1 Row(s), Shrouded

View all PCB Headers

Subtotal (1 pack of 330 units)*

£332.31

(exc. VAT)

£398.77

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 19 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s)
Per Pack
Per unit*
1 +£332.31£1.007

*price indicative

RS Stock No.:
557-356
Mfr. Part No.:
1011106
Brand:
Phoenix Contact
Find similar products by selecting one or more attributes.
Select all

Brand

Phoenix Contact

Series

MC

Product Type

PCB Header

Pitch

3.5mm

Current

8A

Number of Contacts

5

Housing Material

Liquid Crystal Polymer

Number of Rows

1

Shrouded/Unshrouded

Shrouded

Connector System

COMBICON MC 1.5

Mount Type

Wave Soldering Mount

Contact Plating

Tin Plated

Contact Material

Copper Alloy

Row Pitch

3.5mm

Minimum Operating Temperature

-40°C

Termination Type

Solder

Contact Gender

Male

Maximum Operating Temperature

100°C

Tail Pin Length

2.6mm

Standards/Approvals

cULus Recognised, VDE approval of drawings

Mating Pin Length

2.6mm

Voltage

160 V

COO (Country of Origin):
DE
The Phoenix Contact PCB header is designed for seamless integration into the SMT soldering process, offering a high degree of adaptability for modern device design. With a nominal current rating of 8 A and a reliable rated voltage of 160 V, it stands as a robust solution for applications requiring efficiency and safety. Crafted to accommodate up to five positions with a compact 3.5 mm pitch, this component not only meets rigorous performance standards but also provides flexibility in connection technology. Its linear pinning arrangement ensures optimal connectivity, while the Sn-plated surface guarantees superior contact reliability. The product is part of the MC 1.5 series, specifically designed to enhance utilitarian assembly practices while maintaining compliance with industry standards.

Engineered to support through hole reflow soldering techniques

Fits perfectly for devices requiring compact and straightforward assembly

Utilises high-quality copper alloy for enhanced durability

Features a black housing that blends seamlessly with various PCB designs

Compliant with WEEE and RoHS directives, ensuring eco-friendliness

Capable of withstanding rigorous thermal cycling with low moisture sensitivity

Delivers superior insulation resistance for improved safety and reliability

Appropriately packaged in 44 mm wide tape for efficient storage and handling
