Phoenix Contact IPC Series Wave Soldering Mount PCB Header, 6 Contact(s), 10.16 mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 518-769
- Mfr. Part No.:
- 1969658
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£1,215.78
(exc. VAT)
£1,458.94
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 26 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £1,215.78 | £24.316 |
*price indicative
- RS Stock No.:
- 518-769
- Mfr. Part No.:
- 1969658
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Series | IPC | |
| Product Type | PCB Header | |
| Pitch | 10.16mm | |
| Current | 76A | |
| Number of Contacts | 6 | |
| Housing Material | Polyamide | |
| Number of Rows | 1 | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Wave Soldering Mount | |
| Connector System | COMBICON PC 6 hybrid | |
| Contact Plating | Silver | |
| Contact Material | Copper Alloy | |
| Minimum Operating Temperature | -40°C | |
| Row Pitch | 10.16mm | |
| Termination Type | Solder | |
| Maximum Operating Temperature | 105°C | |
| Tail Pin Length | 4mm | |
| Contact Gender | Female | |
| Standards/Approvals | cULus Recognised, IEC 61984, VDE | |
| Mating Pin Length | 4mm | |
| Voltage | 1000 V | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Series IPC | ||
Product Type PCB Header | ||
Pitch 10.16mm | ||
Current 76A | ||
Number of Contacts 6 | ||
Housing Material Polyamide | ||
Number of Rows 1 | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Wave Soldering Mount | ||
Connector System COMBICON PC 6 hybrid | ||
Contact Plating Silver | ||
Contact Material Copper Alloy | ||
Minimum Operating Temperature -40°C | ||
Row Pitch 10.16mm | ||
Termination Type Solder | ||
Maximum Operating Temperature 105°C | ||
Tail Pin Length 4mm | ||
Contact Gender Female | ||
Standards/Approvals cULus Recognised, IEC 61984, VDE | ||
Mating Pin Length 4mm | ||
Voltage 1000 V | ||
- COO (Country of Origin):
- PL
The Phoenix Contact IPC 16/6-GF-10.16 PCB header is engineered for exceptional performance in various applications. This component demonstrates a robust design, ensuring reliable connections through its inverted style and screw locking mechanism. Crafted to facilitate wave soldering, it supports flexible device designs, making it an ideal choice for modern electronic assemblies. Its unique features, including a double steel spring for enhanced safety against thermal fluctuations, set this header apart in the realm of PCB connections. Compliance with stringent manufacturing standards underscores its reliability and durability, ensuring long-lasting service in demanding environments.
Inverted design promotes touch-proof connections
Screw locking mechanism enhances mechanical stability
Compatible with various connection technologies for versatile applications
Robust housing made from PA for improved durability
Double steel spring safeguards against thermal and power variances
Designed for wave soldering, promoting efficient production
Linear pinning ensures precise and secure connections
Green colour coding adds visibility for easy identification
Rated for high voltage applications to meet stringent electrical requirements
Packed in cardboard for eco-friendly and secure storage
