Phoenix Contact IMCV Series Vertical Wave Soldering Mount PCB Header, 4 Contact(s), 3.5 mm Pitch, 1 Row, Shrouded
- RS Stock No.:
- 497-020
- Mfr. Part No.:
- 1830883
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£106.52
(exc. VAT)
£127.82
(inc. VAT)
Stock information currently inaccessible - Please check back later
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £106.52 | £2.13 |
*price indicative
- RS Stock No.:
- 497-020
- Mfr. Part No.:
- 1830883
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Series | IMCV | |
| Product Type | PCB Header | |
| Pitch | 3.5mm | |
| Current | 8A | |
| Housing Material | Liquid Crystal Polymer | |
| Number of Contacts | 4 | |
| Number of Rows | 1 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Wave Soldering Mount | |
| Connector System | COMBICON MC 1.5 | |
| Contact Plating | Tin Plated | |
| Contact Material | Copper Alloy | |
| Termination Type | Solder | |
| Row Pitch | 3.5mm | |
| Minimum Operating Temperature | -40°C | |
| Tail Pin Length | 1.9mm | |
| Maximum Operating Temperature | 100°C | |
| Contact Gender | Female | |
| Standards/Approvals | cULus Recognised, VDE | |
| Mating Pin Length | 1.9mm | |
| Voltage | 160V | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Series IMCV | ||
Product Type PCB Header | ||
Pitch 3.5mm | ||
Current 8A | ||
Housing Material Liquid Crystal Polymer | ||
Number of Contacts 4 | ||
Number of Rows 1 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Wave Soldering Mount | ||
Connector System COMBICON MC 1.5 | ||
Contact Plating Tin Plated | ||
Contact Material Copper Alloy | ||
Termination Type Solder | ||
Row Pitch 3.5mm | ||
Minimum Operating Temperature -40°C | ||
Tail Pin Length 1.9mm | ||
Maximum Operating Temperature 100°C | ||
Contact Gender Female | ||
Standards/Approvals cULus Recognised, VDE | ||
Mating Pin Length 1.9mm | ||
Voltage 160V | ||
- COO (Country of Origin):
- DE
The Phoenix Contact highly versatile PCB header designed specifically for seamless integration into printed circuit boards. This product showcases a robust inverted design with a reliable snap-in locking mechanism, ensuring secure connections and preventing accidental disconnections. With a compact pitch of 3.5 mm and the ability to accommodate four positions, it offers an efficient solution for various electronic applications. This PCB header excels in both performance and durability, featuring a solder pin design that facilitates ease of assembly through THR soldering methods. Constructed with high-quality materials and adhering to stringent safety standards, it guarantees long-lasting reliability even in demanding environments. Its ability to withstand a wide ambient temperature range makes it suitable for diverse operational conditions, further enhancing its applicability across various industries.
Designed for integration into SMT soldering processes
Intuitive locking mechanism enhances connection security
Vertical connection allows for multi-row arrangements on PCBs
Inverted header configuration ensures touch-proof outputs
Packed in environmentally friendly cardboard packaging
WEEE/RoHS compliant, supporting eco-friendly initiatives
Lightweight construction aids in overall device performance
Manufactured with Cu alloy contacts for superior conductivity
