Phoenix Contact DMCV Series Straight Wave Soldering Mount PCB Header, 20 Contact(s), 3.5 mm Pitch, 2 Row(s), Shrouded

View all PCB Headers

Subtotal (1 pack of 50 units)*

£222.05

(exc. VAT)

£266.46

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 10 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s)
Per Pack
Per unit*
1 +£222.05£4.441

*price indicative

RS Stock No.:
483-784
Mfr. Part No.:
1874179
Brand:
Phoenix Contact
Find similar products by selecting one or more attributes.
Select all

Brand

Phoenix Contact

Product Type

PCB Header

Series

DMCV

Pitch

3.5mm

Current

8A

Number of Contacts

20

Housing Material

Liquid Crystal Polymer

Number of Rows

2

Orientation

Straight

Shrouded/Unshrouded

Shrouded

Connector System

COMBICON

Mount Type

Wave Soldering Mount

Contact Plating

Tin Plated

Contact Material

Copper Alloy

Minimum Operating Temperature

-40°C

Termination Type

Solder

Row Pitch

3.5mm

Tail Pin Length

2.6mm

Maximum Operating Temperature

100°C

Contact Gender

Male

Mating Pin Length

2.6mm

Standards/Approvals

cULus Recognised, VDE

Voltage

160 V

COO (Country of Origin):
DE
The Phoenix Contact PCB header is expertly designed for seamless integration into the SMT soldering process, offering both efficiency and stability in electronic connections. With a focus on compact architecture, it enables multi-row arrangements on your PCB, perfectly suitable for applications where space is a critical factor. Its intuitive Lock and Release operating lever simplifies the connection process, while the robust snap-in locking mechanism provides enhanced reliability. The component's superior mechanical stability is complemented by a screwable flange, ensuring it withstands demanding environments. Crafted with high-quality materials and meticulous attention to detail, this product delivers exceptional performance in various electrical and mechanical applications, making it an ideal choice for professional and industrial use.

Designed for efficient integration into the SMT soldering process

Compact size allows for optimal use of space on PCBs

Equipped with a user-friendly Lock and Release operating lever

Features a robust snap-in locking system for reliable connections

Screwable flange enhances overall mechanical stability

Manufactured from high-quality materials ensuring long-lasting performance

Suitable for various applications, combining versatility with durability
