RS PRO Straight Through Hole PCB Header, 3 Contact(s), 1.5mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 147-132
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 bag of 5 units)*
£0.61
(exc. VAT)
£0.73
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 400 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Bag(s) | Per Bag | Per unit* |
---|---|---|
1 - 4 | £0.61 | £0.122 |
5 - 9 | £0.56 | £0.112 |
10 + | £0.50 | £0.10 |
*price indicative
- RS Stock No.:
- 147-132
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Pitch | 1.5mm | |
Number of Contacts | 3 | |
Number of Rows | 1 | |
Body Orientation | Straight | |
Shrouded/Unshrouded | Shrouded | |
Mounting Type | Through Hole | |
Termination Method | Solder | |
Contact Material | Brass | |
Contact Plating | Tin Plated | |
Current Rating | 1A | |
Tail Pin Length | 2.8mm | |
Voltage Rating | 100V | |
Gender | Male | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Pitch 1.5mm | ||
Number of Contacts 3 | ||
Number of Rows 1 | ||
Body Orientation Straight | ||
Shrouded/Unshrouded Shrouded | ||
Mounting Type Through Hole | ||
Termination Method Solder | ||
Contact Material Brass | ||
Contact Plating Tin Plated | ||
Current Rating 1A | ||
Tail Pin Length 2.8mm | ||
Voltage Rating 100V | ||
Gender Male | ||
- COO (Country of Origin):
- CN
RS PRO 1.5mm PCB Header, Top Entry 3 Way
These RS PRO 1.5mm pitch shrouded headers are designed for top entry and through-hole mounting, providing a reliable connection for various electronic applications. Ideal for use in compact PCB designs, they ensure secure and efficient connectivity.
Features and Benefits
1.5 mm pitch: Suitable for compact PCB designs
Voltage Rating: 100V: Ensures safe operation in low voltage applications
Current Rating: 1.0A: Supports adequate current flow for small electronic devices
Low Mating Force: Facilitates easy and secure connections
Reliable contact: Ensures consistent electrical performance
3 Way Top Entry PCB Header: Offers flexibility in design and application
Voltage Rating: 100V: Ensures safe operation in low voltage applications
Current Rating: 1.0A: Supports adequate current flow for small electronic devices
Low Mating Force: Facilitates easy and secure connections
Reliable contact: Ensures consistent electrical performance
3 Way Top Entry PCB Header: Offers flexibility in design and application
Applications
These PCB headers are typically used in consumer electronics, telecommunications, and industrial control systems, where reliable and compact connections are essential.
Additional Information
Contact Material: Brass, providing durability and excellent conductivity
Contact Plating: Tin Plated, enhancing corrosion resistance and solderability
Contact Plating: Tin Plated, enhancing corrosion resistance and solderability
Why RS PRO?
RS PRO is the own brand of RS, offering professional quality products and solutions across all industries and technologies. Our product range is rigorously tested, inspected, and audited against demanding international standards to provide you with industrial-grade quality, at the right price. Making RS PRO your smart choice.
