RS PRO Top Entry Surface Mount PCB Header, 4 Contact(s), 1.5mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 147-053
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 bag of 10 units)*
£3.98
(exc. VAT)
£4.78
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 200 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Bag(s) | Per Bag | Per unit* |
---|---|---|
1 - 4 | £3.98 | £0.398 |
5 - 9 | £3.66 | £0.366 |
10 + | £3.30 | £0.33 |
*price indicative
- RS Stock No.:
- 147-053
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Pitch | 1.5mm | |
Number of Contacts | 4 | |
Number of Rows | 1 | |
Body Orientation | Top Entry | |
Shrouded/Unshrouded | Shrouded | |
Mounting Type | Surface Mount | |
Connector System | Crimp | |
Termination Method | Solder | |
Contact Material | Brass | |
Contact Plating | Tin Plated | |
Current Rating | 1A | |
Tail Pin Length | 1.5mm | |
Voltage Rating | 100V | |
Gender | Male | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Pitch 1.5mm | ||
Number of Contacts 4 | ||
Number of Rows 1 | ||
Body Orientation Top Entry | ||
Shrouded/Unshrouded Shrouded | ||
Mounting Type Surface Mount | ||
Connector System Crimp | ||
Termination Method Solder | ||
Contact Material Brass | ||
Contact Plating Tin Plated | ||
Current Rating 1A | ||
Tail Pin Length 1.5mm | ||
Voltage Rating 100V | ||
Gender Male | ||
- COO (Country of Origin):
- CN
RS PRO SMT Header, 1.5mm Pitch, Top Entry, 4 Way
This RS PRO SMT Header is a compact and efficient solution for PCB connections, featuring a 1.5mm pitch and top entry design. Ideal for applications requiring minimal installation space, it ensures secure and reliable connections with its shrouded design and brass contact material.
Features and Benefits
Compact design: Saves approximately 45% of installation space compared to standard 2mm pitch connectors
1.5mm pitch: Suitable for high-density PCB applications
Top entry SMT type: Facilitates easy surface mounting
Contact retention lances: Allows visual confirmation of contact lock-in for secure insertion
Brass contact material: Ensures reliable electrical performance
Voltage rating of 100V: Suitable for various low-voltage applications
Current rating of 1.0A: Supports moderate current requirements
1.5mm pitch: Suitable for high-density PCB applications
Top entry SMT type: Facilitates easy surface mounting
Contact retention lances: Allows visual confirmation of contact lock-in for secure insertion
Brass contact material: Ensures reliable electrical performance
Voltage rating of 100V: Suitable for various low-voltage applications
Current rating of 1.0A: Supports moderate current requirements
Applications
Ideal for use in consumer electronics, telecommunications, and other industries requiring compact and reliable PCB connections
Additional Information
Contact material: Brass
Contact plating: Tin plated
Termination method: Solder
Contact plating: Tin plated
Termination method: Solder
