Toshiba TLP385(BL,E(T DC Input Optocoupler, Surface Mount, 4-Pin SO
- RS Stock No.:
- 885-1005
- Mfr. Part No.:
- TLP385(BL,E(T
- Brand:
- Toshiba
Bulk discount available
Subtotal (1 pack of 25 units)*
£5.45
(exc. VAT)
£6.55
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit | Per Pack* |
|---|---|---|
| 25 - 25 | £0.218 | £5.45 |
| 50 - 50 | £0.213 | £5.33 |
| 75 - 100 | £0.206 | £5.15 |
| 125 - 225 | £0.201 | £5.03 |
| 250 + | £0.197 | £4.93 |
*price indicative
- RS Stock No.:
- 885-1005
- Mfr. Part No.:
- TLP385(BL,E(T
- Brand:
- Toshiba
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Toshiba | |
| Mount Type | Surface Mount | |
| Product Type | Optocoupler | |
| Maximum Forward Voltage | 1.4V | |
| Number of Channels | 1 | |
| Number of Pins | 4 | |
| Package Type | SO | |
| Input Current Type | DC | |
| Typical Rise Time | 2μs | |
| Maximum Input Current | 50mA | |
| Isolation Voltage | 5000Vrms | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 110°C | |
| Maximum Current Transfer Ratio | 600% | |
| Typical Fall Time | 3μs | |
| Standards/Approvals | UL, EN, CSA | |
| Minimum Current Transfer Ratio | 200% | |
| Series | TLP 385 | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Toshiba | ||
Mount Type Surface Mount | ||
Product Type Optocoupler | ||
Maximum Forward Voltage 1.4V | ||
Number of Channels 1 | ||
Number of Pins 4 | ||
Package Type SO | ||
Input Current Type DC | ||
Typical Rise Time 2μs | ||
Maximum Input Current 50mA | ||
Isolation Voltage 5000Vrms | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 110°C | ||
Maximum Current Transfer Ratio 600% | ||
Typical Fall Time 3μs | ||
Standards/Approvals UL, EN, CSA | ||
Minimum Current Transfer Ratio 200% | ||
Series TLP 385 | ||
Automotive Standard No | ||
Photocoupler, Transistor Output, Toshiba
Optocouplers, Toshiba
