Infineon, AC Motor, Permanent Magnet Control Integrated Power System, 600 V 10 A 24-Pin, DIP
- RS Stock No.:
- 226-6066
- Mfr. Part No.:
- IGCM10F60GAXKMA1
- Brand:
- Infineon
Bulk discount available
View bulk pricing optionsSubtotal (1 tube of 14 units)*
£86.10
(exc. VAT)
£103.32
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 14 unit(s) shipping from 14 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tube* |
|---|---|---|
| 14 - 14 | £6.15 | £86.10 |
| 28 - 56 | £5.842 | £81.79 |
| 70 - 126 | £5.72 | £80.08 |
| 140 - 266 | £5.496 | £76.94 |
| 280 + | £5.429 | £76.01 |
*price indicative
- RS Stock No.:
- 226-6066
- Mfr. Part No.:
- IGCM10F60GAXKMA1
- Brand:
- Infineon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Infineon | |
| Product Type | Control Integrated Power System | |
| Motor Type | AC Motor, Permanent Magnet | |
| Configuration | 3 Phase | |
| Maximum IGBT Collector Current | 10A | |
| Maximum Collector Emitter Voltage Vceo | 600V | |
| Mount Type | Through Hole | |
| Package Type | DIP | |
| Pin Count | 24 | |
| Output Current | 10A | |
| Maximum Supply Voltage | 18.5V | |
| Minimum Supply Voltage | 0V | |
| Minimum Operating Temperature | -40°C | |
| Typical Switching Frequency | 20kHz | |
| Maximum Operating Temperature | 150°C | |
| Length | 33.11mm | |
| Height | 3.1mm | |
| Series | CIPOSTM | |
| Standards/Approvals | RoHS | |
| Width | 25.6mm | |
| Inverter Power Rating | 1200W | |
| Automotive Standard | AEC-Q101 | |
| Select all | ||
|---|---|---|
Brand Infineon | ||
Product Type Control Integrated Power System | ||
Motor Type AC Motor, Permanent Magnet | ||
Configuration 3 Phase | ||
Maximum IGBT Collector Current 10A | ||
Maximum Collector Emitter Voltage Vceo 600V | ||
Mount Type Through Hole | ||
Package Type DIP | ||
Pin Count 24 | ||
Output Current 10A | ||
Maximum Supply Voltage 18.5V | ||
Minimum Supply Voltage 0V | ||
Minimum Operating Temperature -40°C | ||
Typical Switching Frequency 20kHz | ||
Maximum Operating Temperature 150°C | ||
Length 33.11mm | ||
Height 3.1mm | ||
Series CIPOSTM | ||
Standards/Approvals RoHS | ||
Width 25.6mm | ||
Inverter Power Rating 1200W | ||
Automotive Standard AEC-Q101 | ||
The Infineon CIPOS module family offers the chance for integrating various power and control components to increase reliability, optimize PCB size and system costs. It is designed to control three phase AC motor and permanent magnet motor in variable speed drives for applications like a refrigerator and a dish washer. The package concept is specially adapted to power applications, which need good thermal conduction and electrical isolation, but also EMI-save control and overload protection.
Reverse conducting IGBTs with monolithic body diode
Rugged SOI gate driver technology with stability against transient and negative voltage
Over current shutdown
Temperature monitor
Under-voltage lockout at all channels
