- RS Stock No.:
- 170-8184
- Mfr. Part No.:
- HIP4020IBZ
- Brand:
- Renesas Electronics
760 In stock - FREE next working day delivery available
Added
Price Each (In a Tube of 38)
£4.42
(exc. VAT)
£5.30
(inc. VAT)
Units | Per unit | Per Tube* |
38 + | £4.42 | £167.96 |
*price indicative |
- RS Stock No.:
- 170-8184
- Mfr. Part No.:
- HIP4020IBZ
- Brand:
- Renesas Electronics
Legislation and Compliance
- COO (Country of Origin):
- PH
Product Details
HIP4020, Full-Bridge Driver with 500mA Power FETs, Intersil
Two Independent Controlled Complementary MOS Power Output Half-Bridge Drivers (Full-Bridge)
Split Voltage Power Supply Option for Output Drivers
Single Supply Range 2.5 V to 15 V
Low Standby Current
Split Voltage Power Supply Option for Output Drivers
Single Supply Range 2.5 V to 15 V
Low Standby Current
Motor Controllers & Drivers, Intersil
Specifications
Attribute | Value |
---|---|
Motor Type | DC |
Output Configuration | Full Bridge |
Maximum IGBT Collector Current | 0.5A |
Maximum Collector Emitter Voltage | 15 V |
Mounting Type | Surface Mount |
Package Type | SOIC W |
Maximum Operating Supply Voltage | 15 V |
Pin Count | 20 |
Minimum Operating Supply Voltage | 3 V |
Dimensions | 13 x 7.6 x 2.35mm |
Length | 13mm |
Maximum Operating Temperature | +85 °C |
Minimum Operating Temperature | -40 °C |
Height | 2.35mm |
Width | 7.6mm |
