STMicroelectronics STP80N Type N-Channel MOSFET, 5 A, 800 V Enhancement, 3-Pin TO-220 STP80N1K1K6
- RS Stock No.:
- 287-7047P
- Mfr. Part No.:
- STP80N1K1K6
- Brand:
- STMicroelectronics
Bulk discount available
Subtotal 10 units (supplied in a tube)*
£13.60
(exc. VAT)
£16.30
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 298 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 10 + | £1.36 |
*price indicative
- RS Stock No.:
- 287-7047P
- Mfr. Part No.:
- STP80N1K1K6
- Brand:
- STMicroelectronics
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | STMicroelectronics | |
| Channel Type | Type N | |
| Product Type | MOSFET | |
| Maximum Continuous Drain Current Id | 5A | |
| Maximum Drain Source Voltage Vds | 800V | |
| Package Type | TO-220 | |
| Series | STP80N | |
| Mount Type | Through Hole | |
| Pin Count | 3 | |
| Maximum Drain Source Resistance Rds | 1.1mΩ | |
| Channel Mode | Enhancement | |
| Minimum Operating Temperature | -55°C | |
| Maximum Gate Source Voltage Vgs | 30 V | |
| Maximum Power Dissipation Pd | 62W | |
| Forward Voltage Vf | 1.5V | |
| Typical Gate Charge Qg @ Vgs | 5.7nC | |
| Maximum Operating Temperature | 150°C | |
| Standards/Approvals | RoHS | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand STMicroelectronics | ||
Channel Type Type N | ||
Product Type MOSFET | ||
Maximum Continuous Drain Current Id 5A | ||
Maximum Drain Source Voltage Vds 800V | ||
Package Type TO-220 | ||
Series STP80N | ||
Mount Type Through Hole | ||
Pin Count 3 | ||
Maximum Drain Source Resistance Rds 1.1mΩ | ||
Channel Mode Enhancement | ||
Minimum Operating Temperature -55°C | ||
Maximum Gate Source Voltage Vgs 30 V | ||
Maximum Power Dissipation Pd 62W | ||
Forward Voltage Vf 1.5V | ||
Typical Gate Charge Qg @ Vgs 5.7nC | ||
Maximum Operating Temperature 150°C | ||
Standards/Approvals RoHS | ||
Automotive Standard No | ||
- COO (Country of Origin):
- CN
The STMicroelectronics Power MOSFET is designed using the ultimate MDmesh K6 technology based on 20 years STMicroelectronics experience on super junction technology. The result is the best in class on resistance per area and gate charge for applications requiring superior power density and high efficiency.
Worldwide best FOM
Ultra low gate charge
100 percent avalanche tested
