Infineon CoolMOS CPA Type N-Channel MOSFET, 31 A, 600 V Enhancement, 3-Pin PG-TO263-3-2
- RS Stock No.:
- 273-2774
- Mfr. Part No.:
- IPB60R099CPAATMA1
- Brand:
- Infineon
Bulk discount available
Subtotal (1 unit)*
£5.05
(exc. VAT)
£6.06
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 96 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 49 | £5.05 |
| 50 - 99 | £4.30 |
| 100 - 249 | £3.83 |
| 250 - 499 | £3.73 |
| 500 + | £3.49 |
*price indicative
- RS Stock No.:
- 273-2774
- Mfr. Part No.:
- IPB60R099CPAATMA1
- Brand:
- Infineon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Infineon | |
| Channel Type | Type N | |
| Product Type | MOSFET | |
| Maximum Continuous Drain Current Id | 31A | |
| Maximum Drain Source Voltage Vds | 600V | |
| Series | CoolMOS CPA | |
| Package Type | PG-TO263-3-2 | |
| Mount Type | Through Hole | |
| Pin Count | 3 | |
| Maximum Drain Source Resistance Rds | 0.105Ω | |
| Channel Mode | Enhancement | |
| Maximum Gate Source Voltage Vgs | ±20 V | |
| Forward Voltage Vf | 1.2V | |
| Typical Gate Charge Qg @ Vgs | 60nC | |
| Minimum Operating Temperature | -40°C | |
| Maximum Power Dissipation Pd | 255W | |
| Maximum Operating Temperature | 150°C | |
| Height | 1.5mm | |
| Standards/Approvals | RoHS Compliant | |
| Width | 40 mm | |
| Length | 40mm | |
| Automotive Standard | AEC-Q101 | |
| Select all | ||
|---|---|---|
Brand Infineon | ||
Channel Type Type N | ||
Product Type MOSFET | ||
Maximum Continuous Drain Current Id 31A | ||
Maximum Drain Source Voltage Vds 600V | ||
Series CoolMOS CPA | ||
Package Type PG-TO263-3-2 | ||
Mount Type Through Hole | ||
Pin Count 3 | ||
Maximum Drain Source Resistance Rds 0.105Ω | ||
Channel Mode Enhancement | ||
Maximum Gate Source Voltage Vgs ±20 V | ||
Forward Voltage Vf 1.2V | ||
Typical Gate Charge Qg @ Vgs 60nC | ||
Minimum Operating Temperature -40°C | ||
Maximum Power Dissipation Pd 255W | ||
Maximum Operating Temperature 150°C | ||
Height 1.5mm | ||
Standards/Approvals RoHS Compliant | ||
Width 40 mm | ||
Length 40mm | ||
Automotive Standard AEC-Q101 | ||
The Infineon MOSFET is a CoolMOS power transistor. This MOSFET has high peak current capability with worldwide best Rds. This CoolMOS is specially designed for DC to DC converters for automotive applications.
RoHS compliant
Ultra low gate charge
High peak current capability
Automotive AEC Q101 qualified
