STMicroelectronics Dual N-Channel MOSFET, 95 V, 5-Pin LBB
- RS Stock No.:
- 261-5583
- Mfr. Part No.:
- RF5L15120CB4
- Brand:
- STMicroelectronics
Bulk discount available
Subtotal (1 reel of 100 units)*
£14,799.90
(exc. VAT)
£17,759.90
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 28 December 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 100 - 100 | £147.999 | £14,799.90 |
| 200 - 200 | £144.204 | £14,420.40 |
| 300 + | £140.599 | £14,059.90 |
*price indicative
- RS Stock No.:
- 261-5583
- Mfr. Part No.:
- RF5L15120CB4
- Brand:
- STMicroelectronics
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | STMicroelectronics | |
| Channel Type | Dual N | |
| Product Type | MOSFET | |
| Maximum Drain Source Voltage Vds | 95V | |
| Package Type | LBB | |
| Mount Type | Surface | |
| Pin Count | 5 | |
| Maximum Drain Source Resistance Rds | 1Ω | |
| Minimum Operating Temperature | -55°C | |
| Maximum Gate Source Voltage Vgs | 10 V | |
| Maximum Operating Temperature | 150°C | |
| Width | 5.85 mm | |
| Height | 2.1mm | |
| Length | 28.95mm | |
| Standards/Approvals | 2002/95/EC | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand STMicroelectronics | ||
Channel Type Dual N | ||
Product Type MOSFET | ||
Maximum Drain Source Voltage Vds 95V | ||
Package Type LBB | ||
Mount Type Surface | ||
Pin Count 5 | ||
Maximum Drain Source Resistance Rds 1Ω | ||
Minimum Operating Temperature -55°C | ||
Maximum Gate Source Voltage Vgs 10 V | ||
Maximum Operating Temperature 150°C | ||
Width 5.85 mm | ||
Height 2.1mm | ||
Length 28.95mm | ||
Standards/Approvals 2002/95/EC | ||
Automotive Standard No | ||
- COO (Country of Origin):
- CN
The STMicroelectronics 120 W LDMOS FET, designed for broadband commercial communications, TV broadcast, avionics and industrial applications with frequencies from HF to 1.5 GHz. It can be used in class AB/B and class C for all typical modulation formats.
High efficiency and linear gain operations
Integrated ESD protection
Large positive and negative gate or source voltage range
Excellent thermal stability, low HCI drift
