Infineon Dual N Channel OptiMOSTM 2 Type N-Channel MOSFET & Diode, 40 A, 30 V, 8-Pin SuperSO8 5 x 6 BSC0924NDIATMA1
- RS Stock No.:
- 244-1559
- Mfr. Part No.:
- BSC0924NDIATMA1
- Brand:
- Infineon
Bulk discount available
Subtotal (1 pack of 5 units)*
£3.67
(exc. VAT)
£4.405
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 4,805 unit(s) shipping from 29 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 - 20 | £0.734 | £3.67 |
| 25 - 45 | £0.696 | £3.48 |
| 50 - 120 | £0.628 | £3.14 |
| 125 - 245 | £0.564 | £2.82 |
| 250 + | £0.536 | £2.68 |
*price indicative
- RS Stock No.:
- 244-1559
- Mfr. Part No.:
- BSC0924NDIATMA1
- Brand:
- Infineon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Infineon | |
| Product Type | MOSFET & Diode | |
| Channel Type | Type N | |
| Maximum Continuous Drain Current Id | 40A | |
| Maximum Drain Source Voltage Vds | 30V | |
| Package Type | SuperSO8 5 x 6 | |
| Series | OptiMOSTM | |
| Pin Count | 8 | |
| Typical Gate Charge Qg @ Vgs | 6.7nC | |
| Maximum Power Dissipation Pd | 2.5W | |
| Maximum Gate Source Voltage Vgs | ±20 V | |
| Minimum Operating Temperature | -55°C | |
| Forward Voltage Vf | 1V | |
| Transistor Configuration | Dual N Channel | |
| Maximum Operating Temperature | 150°C | |
| Standards/Approvals | JEDEC1, IEC61249-2-22 | |
| Number of Elements per Chip | 2 | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Infineon | ||
Product Type MOSFET & Diode | ||
Channel Type Type N | ||
Maximum Continuous Drain Current Id 40A | ||
Maximum Drain Source Voltage Vds 30V | ||
Package Type SuperSO8 5 x 6 | ||
Series OptiMOSTM | ||
Pin Count 8 | ||
Typical Gate Charge Qg @ Vgs 6.7nC | ||
Maximum Power Dissipation Pd 2.5W | ||
Maximum Gate Source Voltage Vgs ±20 V | ||
Minimum Operating Temperature -55°C | ||
Forward Voltage Vf 1V | ||
Transistor Configuration Dual N Channel | ||
Maximum Operating Temperature 150°C | ||
Standards/Approvals JEDEC1, IEC61249-2-22 | ||
Number of Elements per Chip 2 | ||
Automotive Standard No | ||
The Infineon has MOSFET which is OptiMOS power MOSFET,Integrated monolithic Schottky-like diode and Optimized for high performance Buck converter.
N Channel
100% Avalanche tested
AEC Q101 qualified
MSL1 up to 260°C peak reflow
175°C operating temperature
Green Product (RoHS compliant)
