Vishay N-Channel 30 V Type N-Channel MOSFET, 437 A, 30 V, 4-Pin PowerPAK (8x8L) SQJ128ELP-T1_GE3
- RS Stock No.:
- 225-9946
- Mfr. Part No.:
- SQJ128ELP-T1_GE3
- Brand:
- Vishay
Bulk discount available
Subtotal (1 pack of 10 units)*
£10.51
(exc. VAT)
£12.61
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 27 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 10 - 90 | £1.051 | £10.51 |
| 100 - 240 | £1.019 | £10.19 |
| 250 - 490 | £0.966 | £9.66 |
| 500 - 990 | £0.925 | £9.25 |
| 1000 + | £0.872 | £8.72 |
*price indicative
- RS Stock No.:
- 225-9946
- Mfr. Part No.:
- SQJ128ELP-T1_GE3
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Product Type | MOSFET | |
| Channel Type | Type N | |
| Maximum Continuous Drain Current Id | 437A | |
| Maximum Drain Source Voltage Vds | 30V | |
| Series | N-Channel 30 V | |
| Package Type | PowerPAK (8x8L) | |
| Mount Type | Surface | |
| Pin Count | 4 | |
| Maximum Drain Source Resistance Rds | 2mΩ | |
| Maximum Gate Source Voltage Vgs | 20 V | |
| Forward Voltage Vf | 1.1V | |
| Typical Gate Charge Qg @ Vgs | 99nC | |
| Maximum Power Dissipation Pd | 500W | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 175°C | |
| Height | 1.1mm | |
| Width | 5 mm | |
| Standards/Approvals | No | |
| Length | 6.25mm | |
| Automotive Standard | AEC-Q101 | |
| Select all | ||
|---|---|---|
Brand Vishay | ||
Product Type MOSFET | ||
Channel Type Type N | ||
Maximum Continuous Drain Current Id 437A | ||
Maximum Drain Source Voltage Vds 30V | ||
Series N-Channel 30 V | ||
Package Type PowerPAK (8x8L) | ||
Mount Type Surface | ||
Pin Count 4 | ||
Maximum Drain Source Resistance Rds 2mΩ | ||
Maximum Gate Source Voltage Vgs 20 V | ||
Forward Voltage Vf 1.1V | ||
Typical Gate Charge Qg @ Vgs 99nC | ||
Maximum Power Dissipation Pd 500W | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 175°C | ||
Height 1.1mm | ||
Width 5 mm | ||
Standards/Approvals No | ||
Length 6.25mm | ||
Automotive Standard AEC-Q101 | ||
The Vishay Siliconix maintains Reliability data for Semiconductor Technology and Package Reliability represent a composite of all qualified locations.
AEC-Q101 qualified
100 % Rg and UIS tested
Thin 1.6 mm package
Very low thermal resistance
