onsemi PowerTrench Type N-Channel MOSFET, 6.1 A, 60 V Enhancement, 8-Pin SOIC

View all MOSFETs
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
RS Stock No.:
166-3360
Mfr. Part No.:
FDS5351
Brand:
onsemi
Find similar products by selecting one or more attributes.
Select all

Brand

onsemi

Product Type

MOSFET

Channel Type

Type N

Maximum Continuous Drain Current Id

6.1A

Maximum Drain Source Voltage Vds

60V

Package Type

SOIC

Series

PowerTrench

Mount Type

Surface

Pin Count

8

Maximum Drain Source Resistance Rds

58.8mΩ

Channel Mode

Enhancement

Typical Gate Charge Qg @ Vgs

19nC

Minimum Operating Temperature

-55°C

Maximum Power Dissipation Pd

5W

Maximum Gate Source Voltage Vgs

20 V

Forward Voltage Vf

1.3V

Maximum Operating Temperature

150°C

Height

1.57mm

Standards/Approvals

No

Width

3.9 mm

Length

4.9mm

Automotive Standard

No

PowerTrench® N-Channel MOSFET, up to 9.9A, Fairchild Semiconductor


MOSFET Transistors, ON Semi


ON Semi offers a substantial portfolio of MOSFET devices that includes high-voltage (>250V) and low-voltage (<250V) types. The Advanced silicon technology provides smaller die sizes, which it is incorporated into multiple industry-standard and thermally-enhanced packages.

ON Semi MOSFETs provide superior design reliability from reduced voltage spikes and overshoot, to lower junction capacitance and reverse recovery charge, to elimination of additional external components to keep systems up and running longer.
