Infineon IPQ Type N-Channel MOSFET, 30 A, 60 V Enhancement, 22-Pin PG-HDSOP-22 IPQC60T017S7AXTMA1

RS Stock No.:: 349-200
Mfr. Part No.:: IPQC60T017S7AXTMA1
Brand:: Infineon

Infineon IPQ Type N-Channel MOSFET, 30 A, 60 V Enhancement, 22-Pin PG-HDSOP-22 IPQC60T017S7AXTMA1

Bulk discount available

Subtotal (1 unit)*

£15.39

(exc. VAT)

£18.47

(inc. VAT)

FREE delivery for orders over £50.00

Temporarily out of stock

Shipping from 04 May 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 - 9	£15.39
10 - 99	£13.85
100 +	£12.77

*price indicative

RS Stock No.:: 349-200
Mfr. Part No.:: IPQC60T017S7AXTMA1
Brand:: Infineon

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Infineon
	Product Type	MOSFET
	Channel Type	Type N
	Maximum Continuous Drain Current Id	30A
	Maximum Drain Source Voltage Vds	60V
	Series	IPQ
	Package Type	PG-HDSOP-22
	Mount Type	Surface
	Pin Count	22
	Maximum Drain Source Resistance Rds	17mΩ
	Channel Mode	Enhancement
	Maximum Power Dissipation Pd	500W
	Typical Gate Charge Qg @ Vgs	196nC
	Minimum Operating Temperature	-40°C
	Forward Voltage Vf	0.82V
	Maximum Gate Source Voltage Vgs	20 V
	Maximum Operating Temperature	150°C
	Standards/Approvals	RoHS, JEDEC, AEC Q101
	Automotive Standard	AEC-Q101

	Select all
	Brand Infineon
	Product Type MOSFET
	Channel Type Type N
	Maximum Continuous Drain Current Id 30A
	Maximum Drain Source Voltage Vds 60V
	Series IPQ
	Package Type PG-HDSOP-22
	Mount Type Surface
	Pin Count 22
	Maximum Drain Source Resistance Rds 17mΩ
	Channel Mode Enhancement
	Maximum Power Dissipation Pd 500W
	Typical Gate Charge Qg @ Vgs 196nC
	Minimum Operating Temperature -40°C
	Forward Voltage Vf 0.82V
	Maximum Gate Source Voltage Vgs 20 V
	Maximum Operating Temperature 150°C
	Standards/Approvals RoHS, JEDEC, AEC Q101
	Automotive Standard AEC-Q101

Datasheet - IPQC60T017S7AXTMA1

COO (Country of Origin):: MY

The Infineon CoolMOS S7TA enables the best price performance for low frequency switching applications. The embedded temperature sensor increases junction temperature sensing accuracy and robustness while keeping an easy and seamless implementation. CoolMOS S7TA is optimized for static switching and high current applications. The new temperature sensor enhances S7A features, allowing the best possible utilization of the power transistor.

Optimized price performance in low frequency switching applications

High pulse current capability

Seamless diagnostics at lowest system cost

Increased system performance

Minimized conduction losses

More reliability and longer system lifetime

Shock and vibration resistance

No contact arcing or bouncing
