Microchip ATMEGA16A-PU, 8bit AVR Microcontroller, ATmega, 16MHz, 16 kB Flash, 40-Pin PDIP

RS Stock No.:: 127-8277
Mfr. Part No.:: ATMEGA16A-PU
Brand:: Microchip

Microchip ATMEGA16A-PU, 8bit AVR Microcontroller, ATmega, 16MHz, 16 kB Flash, 40-Pin PDIP

Available to back order for despatch when stock is available

Price Each (In a Pack of 2)

£3.47

(exc. VAT)

£4.16

(inc. VAT)

Units	Per unit	Per Pack*
2 - 8	£3.47	£6.94
10 - 22	£3.355	£6.71
24 - 98	£3.275	£6.55
100 +	£3.205	£6.41

*price indicative

RS Stock No.:: 127-8277
Mfr. Part No.:: ATMEGA16A-PU
Brand:: Microchip

Technical Reference

Legislation and Compliance

COO (Country of Origin):: US

Product Details

8-Bit megaAVR Microcontrollers, 4KB to 16KB Flash

Here at RS Components we have numerous megaAVR 8-bit microcontrollers from Atmel.Each microcontroller is based on an enhanced RISC architecture and features QTouch library support. All of the megaAVR microcontrollers have varying Kb of In-System Programmable Flash, EEPROM and SRAM as well as a variety of pin and package types.

Types of megaAVR 8-bit microcontrollers
•ATmega8
•ATmega16
•ATmega48
•ATmega88
•ATmega162
•ATmega164
•ATmega165
•ATmega168
•ATmega8515
•ATmega8535

Specifications

Attribute	Value
Family Name	ATmega
Package Type	PDIP
Mounting Type	Through Hole
Pin Count	40
Device Core	AVR
Data Bus Width	8bit
Program Memory Size	16 kB
Maximum Frequency	16MHz
RAM Size	1 kB
USB Channels	0
Number of PWM Units	1
Number of SPI Channels	1
Number of USART Channels	1
Number of CAN Channels	0
Number of I2C Channels	1
Typical Operating Supply Voltage	2.7 → 5.5 V
Number of UART Channels	1
Width	13.97mm
Height	4.44mm
ADCs	8 x 10 bit
Length	52.57mm
Dimensions	52.57 x 13.97 x 4.44mm
Maximum Operating Temperature	+85 °C
Number of Ethernet Channels	0
Program Memory Type	Flash
Pulse Width Modulation	1 (4 Channel)
Minimum Operating Temperature	-40 °C
Instruction Set Architecture	RISC
Maximum Number of Ethernet Channels	0
Number of ADC Units	1
