Europa EUC3P EUC MCB, 3P, 63A Curve C, 230V AC, 10 kA Breaking Capacity
- RS Stock No.:
- 849-6608
- Mfr. Part No.:
- EUC3P63C
- Brand:
- Europa
163 In stock - FREE next working day delivery available
Price Each
£17.60
(exc. VAT)
£21.12
(inc. VAT)
| Units | Per unit |
| 1 + | £17.60 |
- RS Stock No.:
- 849-6608
- Mfr. Part No.:
- EUC3P63C
- Brand:
- Europa
Technical Reference
Legislation and Compliance
RoHS Status: Not Applicable
- COO (Country of Origin):
- CN
Product Details
Europacomponents MCBs
This range of MCB's are suitable for fitting into consumer units, they have been fully tested and conform to the relevant standards to ensure safety, protection and reliability.
From 6A to 63A
Terminal capacity: 1mm2 to 25mm2
Operating temperature -5° to 40°C
35mm DIN Rail mounting
IP20
Terminal capacity: 1mm2 to 25mm2
Operating temperature -5° to 40°C
35mm DIN Rail mounting
IP20
Standards
IEC 60898, EN 60898
Approvals
CE, SEMKO
Europacomponents Circuit Protection Devices
Specifications
Attribute | Value |
|---|---|
| Number of Poles | 3P |
| Current Rating | 63A |
| Tripping Characteristics | Type C |
| Rated AC Voltage | 230 V, 400V |
| Breaking Capacity at Maximum Voltage Rating | 10 kA |
| Range | EUC3P |
| Series | EUC |
| Circuit Breaker Type | MCB |
| Length | 54mm |
| Width | 78mm |
| Mounting Style | DIN Rail Mount |
| Depth | 87mm |
| Model Number | EUC3P63C |
