Europa EUC3P EUC MCB, 3P, 50A Curve C, 230V AC, 10 kA Breaking Capacity
- RS Stock No.:
- 849-6604
- Mfr. Part No.:
- EUC3P50C
- Brand:
- Europa
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 849-6604
- Mfr. Part No.:
- EUC3P50C
- Brand:
- Europa
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Europa | |
Number of Poles | 3 | |
Current Rating | 50A | |
Tripping Characteristics | Type C | |
Rated AC Voltage | 230 V, 400V | |
Breaking Capacity at Maximum Voltage Rating | 10 kA | |
Range | EUC3P | |
Series | EUC | |
Circuit Breaker Type | MCB | |
Length | 54mm | |
Width | 78mm | |
Mounting Style | DIN Rail Mount | |
Depth | 87mm | |
Model Number | EUC3P50C | |
Select all | ||
---|---|---|
Brand Europa | ||
Number of Poles 3 | ||
Current Rating 50A | ||
Tripping Characteristics Type C | ||
Rated AC Voltage 230 V, 400V | ||
Breaking Capacity at Maximum Voltage Rating 10 kA | ||
Range EUC3P | ||
Series EUC | ||
Circuit Breaker Type MCB | ||
Length 54mm | ||
Width 78mm | ||
Mounting Style DIN Rail Mount | ||
Depth 87mm | ||
Model Number EUC3P50C | ||
RoHS Status: Exempt
- COO (Country of Origin):
- CN
Europacomponents MCBs
This range of MCB's are suitable for fitting into consumer units, they have been fully tested and conform to the relevant standards to ensure safety, protection and reliability.
From 6A to 63A
Terminal capacity: 1mm2 to 25mm2
Operating temperature -5° to 40°C
35mm DIN Rail mounting
IP20
Terminal capacity: 1mm2 to 25mm2
Operating temperature -5° to 40°C
35mm DIN Rail mounting
IP20
Standards
IEC 60898, EN 60898
Approvals
CE, SEMKO
