Eaton xEffect MCB, 2P, 2A Curve C, 240 → 415V AC, 10 kA Breaking Capacity
- RS Stock No.:
- 847-3291
- Mfr. Part No.:
- 102160 FAZ-C2/2-NA
- Brand:
- Eaton
Subtotal (1 unit)*
£91.25
(exc. VAT)
£109.50
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 9 unit(s) shipping from 06 October 2025
- Plus 2 unit(s) shipping from 06 October 2025
- Plus 999,999,990 unit(s) shipping from 24 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £91.25 |
*price indicative
- RS Stock No.:
- 847-3291
- Mfr. Part No.:
- 102160 FAZ-C2/2-NA
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Eaton | |
Number of Poles | 2 | |
Current Rating | 2A | |
Tripping Characteristics | Type C | |
Rated AC Voltage | 240 → 415V | |
Breaking Capacity at Maximum Voltage Rating | 10 kA | |
Range | xEffect | |
Circuit Breaker Type | MCB | |
Width | 105mm | |
Length | 35.4mm | |
Mounting Style | DIN Rail Mount | |
Depth | 76mm | |
Select all | ||
---|---|---|
Brand Eaton | ||
Number of Poles 2 | ||
Current Rating 2A | ||
Tripping Characteristics Type C | ||
Rated AC Voltage 240 → 415V | ||
Breaking Capacity at Maximum Voltage Rating 10 kA | ||
Range xEffect | ||
Circuit Breaker Type MCB | ||
Width 105mm | ||
Length 35.4mm | ||
Mounting Style DIN Rail Mount | ||
Depth 76mm | ||
Eaton FAZ Series Circuit Breakers
The FAZ series by Eaton offers a wide range of quality, highly reliable and safe circuit breakers. Eatons FAZ DIN rail mountable circuit breaker is designed for use in control panel applications.
Features and Benefits
The Eaton miniature circuit breaker has a current limiting design, providing short circuit interruption to reduce let-through energy, which can damage the circuit.
Rated currents up to 63A.
The toggle can be sealed in both the on and off position where required, and the trip-free design means that the breaker cannot be defeated by holding the handle in the on position.
Reliable and safe operation with six levels of thermal-magnetic over-current protection.
Red or green light indicates the contact position.
Easy installation.
Suitable for supplementary protection.
Rated currents up to 63A.
The toggle can be sealed in both the on and off position where required, and the trip-free design means that the breaker cannot be defeated by holding the handle in the on position.
Reliable and safe operation with six levels of thermal-magnetic over-current protection.
Red or green light indicates the contact position.
Easy installation.
Suitable for supplementary protection.
Note
Eaton formerly known as Moeller
