ABB System Pro M Compact S200 Miniature Circuit Breaker, 2-Pole, 80A, Type B, 400V ac AC, 6 kA Breaking Capacity

View all MCBs

Subtotal (1 unit)*

£97.50

(exc. VAT)

£117.00

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • Plus 1 unit(s) shipping from 07 May 2026
  • Plus 3 unit(s) shipping from 07 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£97.50

*price indicative

Better World

Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.

RS Stock No.:
237-3233
Mfr. Part No.:
2CDS252001R0805 S202-B80 6kA
Brand:
ABB
Find similar products by selecting one or more attributes.
Select all

Brand

ABB

Number of Poles

2

Product Type

Miniature Circuit Breaker

Current Rating

80A

Tripping Characteristics

Type B

Rated AC Voltage

400V ac

Mount Type

DIN Rail

Breaking Capacity

6kA

Range

System Pro M Compact

Series

S200

Terminal Type

Screw

IP Rating

IP40, IP20

Depth

69mm

Height

88mm

Width

35mm

Standards/Approvals

IEC/EN 60947-2, IEC/EN 60898-1

Better World Claim

Designed for Disassembly

Better World Product

Yes

Reset Actuator Type

Toggle Switch

Tripping Mechanism

Electromagnetic, Thermomagnetic

COO (Country of Origin):
DE

ABB S200 Series Miniature Circuit Breaker, 80A Current, 400V AC Rated AC Voltage - 2CDS252001R0805 S202-B80 6kA


This miniature circuit breaker provides Compact overcurrent protection for low-voltage installations and distribution panels. Designed for two-pole applications, it interrupts fault currents on 400V AC systems and is mounted on DIN rail for straightforward integration into control and distribution assemblies.

Features & Benefits


• 80A rating delivers high continuous current capacity for heavy loads
• 6kA breaking capacity limits prospective fault energy exposure
• Type B thermomagnetic tripping protects against overload and short-circuit
• Electromagnetic trip breaker 80A enables Rapid disconnection on faults
• Screw Terminal MCB offers secure, maintenance-friendly conductor connections
• IP20 and IP40 variant provides Basic enclosure protection suitable for panel mounting

Applications


• Suitable for industrial control panels supplying motors and drives
• Ideal for distribution boards in commercial electrical installations
• used with automation racks requiring 2-pole isolation and protection
• Can be used for protection of downstream circuits in switchgear assemblies

What mounting method does it use for panel installation?


It is designed for DIN-rail mounting, enabling quick Snap-on attachment and simple removal during maintenance.

How many poles does it occupy and how does that affect wiring?


It is a 2-pole device, allowing simultaneous disconnection of both live conductors in single-phase or two-wire circuits.

Which tripping mechanisms are incorporated and what is their function?


It combines thermomagnetic and electromagnetic tripping

thermal action handles prolonged overloads while electromagnetic action provides instantaneous response to high short-circuit currents.

What Terminal arrangement is provided for conductor termination?


The unit uses screw terminals to secure conductors, supporting reliable clamping and routine servicing without specialised tools.
